RF-16
SUNROOF
Revision: August 20072004 QX56
CONSULT-II Function (BCM)EIS002WQ
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II OPERATION
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and CON-
SULT-II CONVERTER to the data link connector, then turn igni-
tion switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "BCM".
If "BCM" is not indicated, go to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
BCM diagnostic
test itemDiagnostic mode Description
Inspection by partWORK SUPPORTSupports inspections and adjustments. Commands are transmitted to the BCM
for setting the status suitable for required operation, input/output signals are
received from the BCM and received data is displayed.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
BCIA0030E
Page 2818 of 3371

SUNROOF
RF-17
C
D
E
F
G
H
J
K
L
MA
B
RF
Revision: August 20072004 QX56
4. Touch "RETAINED PWR".
5. Select diagnosis mode. "DATA MONITOR", "ACTIVE TEST" and
"WORK SUPPORT" are available.
Work Support EIS002WT
Active TestEIS002WS
Data MonitorEIS002WR
Trouble Diagnosis Chart by SymptomEIS002WU
LIIA0163E
BCIA0031E
Work item Description
RETAINED PWR SETRAP signal’s power supply period can be changed by mode setting. Select RAP signal’s
power supply period between the following three mode settings:
MODE 1 (45 sec.) / MODE 2 (OFF) / MODE 3 (2 min.)
Test item Description
RETAINED PWRThis test is able to supply RAP signal (power) from BCM to power window system, power
sunroof system. Those systems can be operated when turning on “RETAINED PWR” on
CONSULT-II screen even if the ignition switch is turned OFF.
NOTE:
During this test, CONSULT-II can be operated with ignition switch “OFF” position.
“RETAINED PWR” should be turned “ON” or “OFF” on CONSULT-II screen when
ignition switch ON. Then turn ignition switch OFF for checking retained power
operation. CONSULT-II might be stuck if “RETAINED PWR” is turned “ON” or “OFF”
on CONSULT-II screen when ignition switch is OFF.
Monitored item Description
IGN ON SW Indicates [ON/OFF] condition of ignition switch.
DOOR SW-DR Indicates [ON/OFF] condition of front door switch driver side.
DOOR SW-AS Indicates [ON/OFF] condition of front door switch passenger side.
Symptom Diagnostic procedure and repair order Refer to page
Sunroof does not operate.1. Sunroof motor assembly power supply and
ground circuit checkRF-20
2. Sunroof switch system checkRF-19
3. BCM power supply and ground circuit checkRF-18
4. Replace sunroof motor assemblyRF-27
Page 2819 of 3371

RF-18
SUNROOF
Revision: August 20072004 QX56
BCM Power Supply and Ground Circuit CheckEIS002WV
1. CHECK FUSE
Check the following BCM fuse and fusible link.
NOTE:
Refer to RF-10, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of problem before installing new fuse. Refer to PG-4,
"POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connectors.
3. Check voltage between BCM connectors M18 and M20 termi-
nals 38, 70 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. CHECK GROUND CIRCUIT
Check continuity between BCM connector M20 terminals 67 and
ground.
OK or NG
OK >> Power supply and ground circuits are OK.
NG >> Repair or replace harness.
Retained power operation does not operate properly.1. Check the retained power operation mode settingRF-112. BCM power supply and ground circuit checkRF-18
3. Door switch checkRF-22
4. Replace sunroof motor assemblyRF-27
Motor does not stop at the sunroof fully-open or fully-closed
position.1. Initialization procedure checkRF-11
2. Replace sunroof motor assemblyRF-27
Sunroof does not do the interruption detection. 1. Replace sunroof motor assemblyRF-27
Symptom Diagnostic procedure and repair order Refer to page
Component Parts Terminal No. (SIGNAL) Ampere No. Location
BCM38 (IGN power supply) 10A 59 Fuse and relay box
70 (BAT power supply) 50A f Fuse and fusible link box
ConnectorTerminals
(Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
M18 38 (W/L)
GroundIgnition switch ON
Battery voltage
M20 70 (W/B) Ignition switch OFF
WIIA0229E
Connector Terminals (Wire color) Continuity
M20 67 (B) Ground Yes
WIIA0230E
Page 2820 of 3371

SUNROOF
RF-19
C
D
E
F
G
H
J
K
L
MA
B
RF
Revision: August 20072004 QX56
Sunroof Switch System CheckEIS002WW
1. CHECK SUNROOF MOTOR ASSEMBLY INPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between sunroof motor assembly connector and
ground.
OK or NG
OK >> Replace Sunroof Motor Assembly. Refer to RF-27, "SUNROOF MOTOR" .
NG >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Disconnect sunroof motor assembly connector.
2. Check continuity between sunroof motor assembly connector R4 (A) terminals 3, 4, 8, 9 and 10 and sun-
roof switch connector R104 (B) terminals 1, 2, 3, 4 and 6.
3. Check continuity between sunroof motor assembly connector
R4 (A) terminals 3, 4, 8, 9 and 10 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness between sunroof motor assembly and sunroof switch.
ConnectorTerminal
(Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
R43 (P/W)
GroundSunroof switch in
CLOSE position0
Other than aboveBattery
voltage
4 (O)Sunroof switch in TILT
UP position0
Other than aboveBattery
voltage
9 (P)Sunroof switch in
OPEN position0
Other than aboveBattery
voltage
10 (L/R)Sunroof switch in TILT
DOWN position0
Other than aboveBattery
voltage
WIIA0249E
3 (P/W) - 1 (P/W) : Continuity should exist.
4 (O) - 4 (O) : Continuity should exist.
8 (Y) - 2 (Y) : Continuity should exist.
9 (P) - 3 (P) : Continuity should exist.
10 (L/R) - 6 (L/R) : Continuity should exist.
3 (P/W) - Ground : Continuity should not exist.
4 (O) - Ground : Continuity should not exist.
8 (Y) - Ground : Continuity should not exist.
9 (P) - Ground : Continuity should not exist.
10 (L/R) - Ground : Continuity should not exist.
WIIA0744E
Page 2821 of 3371

RF-20
SUNROOF
Revision: August 20072004 QX56
3. CHECK SUNROOF SWITCH
1. Disconnect sunroof switch connector.
2. Operate sunroof slide switch, and check continuity of the sun-
roof switch as follows.
OK or NG
OK >> Check the condition of the harness and connector.
NG >> Replace sunroof switch.
Sunroof Motor Assembly Power Supply and Ground Circuit CheckEIS002WX
1. CHECK POWER SUPPLY CIRCUIT
1. Disconnect the sunroof motor assembly connector.
2. Check voltage between sunroof motor assembly connector R4
terminals 1, 5 and ground.
*: For explanation of the three available mode settings, refer to RF-17, "
Work Support" .
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
Terminal Condition Continuity
1
2Sunroof switch in CLOSE position Yes
Other than above No
3Sunroof switch in OPEN position Yes
Other than above No
4Sunroof switch in TILT UP position Yes
Other than above No
6Sunroof switch in TILT DOWN position Yes
Other than above No
WIIA0232E
ConnectorTerminals (Wire color)
Condition Voltage
(Approx.)
(+) (–)
R4 1 (W/L) GroundIgnition switch ON Battery voltage
Within 45 seconds after
ignition switch is turned
OFF and all doors closed
(Mode 1)
*
Battery voltage
With ignition switch OFF
(Mode 2)*0
Within 2 minutes after
ignition switch is turned
OFF and all doors closed
(Mode 3)
*
Battery voltage
When front door LH or
RH is open while retained
power is operating.0
5 (W/R) Ignition switch OFF Battery voltage
WIIA0250E
Page 2822 of 3371

SUNROOF
RF-21
C
D
E
F
G
H
J
K
L
MA
B
RF
Revision: August 20072004 QX56
2. CHECK SUNROOF MOTOR CIRCUIT HARNESS
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM connector M20 terminals 68 and
69 and sunroof motor assembly connector R4 terminals 1 and 5.
4. Check continuity between BCM connector M20 terminal 68, 69
and ground.
OK or NG
OK >> Replace BCM. Refer to BCS-19, "Removal and Installation of BCM" .
NG >> Repair or replace harness between BCM and sunroof motor assembly.
3. CHECK GROUND CIRCUIT
Check continuity between sunroof motor assembly connector R4 terminal 7 and ground.
OK or NG
OK >> Sunroof motor assembly power supply and ground cir-
cuits are OK.
NG >> Repair or replace harness.68 (W/L) - 1 (W/L) : Continuity should exist.
69 (W/R) - 5 (W/R) : Continuity should exist.
68 (W/L) - Ground : Continuity should not exist.
69 (W/R) - Ground : Continuity should not exist.
LIIA2251E
7 (B) - Ground : Continuity should exist.
WIIA0251E
Page 2823 of 3371

RF-22
SUNROOF
Revision: August 20072004 QX56
Door Switch CheckEIS002WY
1. CHECK DOOR SWITCH INPUT SIGNAL
With CONSULT-II
Check door switches (“DOOR SW-DR” and “DOOR SW-AS”) in “DATA MONITOR” mode with CONSULT-II.
Without CONSULT-II
1. Turn ignition switch OFF.
2. Check voltage between BCM connector and ground.
OK or NG
OK >> Door switches are OK.
NG >> GO TO 2.
2. CHECK DOOR SWITCH CIRCUIT
1. Disconnect front door switches and BCM connectors.
2. Check continuity between front door switch connector B8 (LH) or B108 (RH) terminal 2 and BCM connec-
tor M18, M19 terminals 12 and 47.
3. Check continuity between front door switch connector B8 (LH)
or B108 (RH) terminal 2 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness between BCM and door switch.
Monitor item Condition
DOOR SW-DROPEN : ON
CLOSE : OFF
DOOR SW-ASOPEN : ON
CLOSE : OFF
PIIA2464E
Item ConnectorTe r m i n a l s ( W i r e
color)
ConditionVoltage (V)
(Approx.)
(+) (–)
RH M18 12 (R/L)
GroundDoor Open
(switch closed)0
Door Closed
(switch open)Battery
voltage
LH M19 47 (SB)Door Open
(switch closed)0
Door Closed
(switch open)Battery
voltage
WIIA0234E
Front door switch LH
2 (SB) - 47 (SB) : Continuity should exist.
Front door switch RH
2 (R/L) - 12 (R/L) : Continuity should exist.
2 (SB or R/L) - Ground : Continuity should not exist.
WIIA0235E
Page 2824 of 3371
SUNROOF
RF-23
C
D
E
F
G
H
J
K
L
MA
B
RF
Revision: August 20072004 QX56
3. CHECK DOOR SWITCH
Check continuity between each door switch terminal 2 and body ground part of door switch.
OK or NG
OK >> GO TO 4.
NG >> Replace malfunctioning door switch.
4. CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between BCM connector M18 terminal 12, M19 terminal 47 and ground.
OK or NG
OK >> Check the condition of the harness and the connector.
NG >> Replace BCM. Refer to BCS-19, "
Removal and Installa-
tion of BCM" .
Terminal Condition Continuity
2Body ground part
of door switchDoor switch pushed No
Door switch released Yes
WIIA0289E
12 (R/L) - Ground : Battery voltage
47 (SB) - Ground : Battery voltage
