Page 1857 of 3371

INFINITI QX56 2004 Factory Service Manual EI-16 REAR BUMPER Revision: August 20072004 QX56 1. Remove quarter panel trim covers LH and RH. 2. Disconnect sonar sensor harness connector under rear fascia assembly. 3. Release retainer clips on bo

Page 1858 of 3371

INFINITI QX56 2004 Factory Service Manual FRONT GRILLE EI-17 C D E F G H J K L MA B EI Revision: August 20072004 QX56 FRONT GRILLEPFP:62310 Removal and InstallationEIS002X9 1. Remove bolts and nuts attaching grille. 2. Remove grille. Installa

Page 1859 of 3371

INFINITI QX56 2004 Factory Service Manual EI-18 COWL TOP Revision: August 20072004 QX56 COWL TOPPFP:66100 Removal and InstallationEIS002XA 1. Remove right and left wiper arms. Refer to WW-29, "Removal and Installation of Front Wiper Arms, Adj

Page 1860 of 3371

INFINITI QX56 2004 Factory Service Manual COWL TOP EI-19 C D E F G H J K L MA B EI Revision: August 20072004 QX56 5. Remove wiper motor and connecting rod linkage. Refer to WW-29, "Removal and Installation of Wiper Motor and Linkage" . 6. Di

Page 1861 of 3371

INFINITI QX56 2004 Factory Service Manual EI-20 FRONT FENDER Revision: August 20072004 QX56 FRONT FENDERPFP:63100 Removal and InstallationEIS002XB 1. Remove headlamp. Refer to LT- 3 3 , "Removal and Installation" . 2. Remove over fender. Re

Page 1862 of 3371

INFINITI QX56 2004 Factory Service Manual OVER FENDER EI-21 C D E F G H J K L MA B EI Revision: August 20072004 QX56 OVER FENDERPFP:63810 Removal and InstallationEIS002ZX REMOVAL 1. Remove screws from front and/or rear over fender. CAUTION: N

Page 1863 of 3371

INFINITI QX56 2004 Factory Service Manual EI-22 OVER FENDER Revision: August 20072004 QX56 6. Secure front and/or rear over fender with screws.

Page 1864 of 3371

INFINITI QX56 2004 Factory Service Manual FENDER PROTECTOR EI-23 C D E F G H J K L MA B EI Revision: August 20072004 QX56 FENDER PROTECTORPFP:63840 Removal and InstallationEIS002XC FRONT 1. Remove screws. 2. Remove plastic clips. 3. Remove fr
