Page 2409 of 3371

INFINITI QX56 2004 Factory Service Manual LAN-146 [CAN] CAN SYSTEM (TYPE 4) Revision: August 20072004 QX56 Case 12 Check display control unit circuit. Refer to LAN-162, "Display Control Unit Circuit Check" . PKIA8123E PKIA8829E

Page 2410 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 4) LAN-147 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 Case 13 Check BCM circuit. Refer to LAN-162, "BCM Circuit Check" . PKIA8124E PKIA8830E

Page 2411 of 3371

INFINITI QX56 2004 Factory Service Manual LAN-148 [CAN] CAN SYSTEM (TYPE 4) Revision: August 20072004 QX56 Case 14 Check data link connector circuit. Refer to LAN-163, "Data Link Connector Circuit Check" . PKIA8125E PKIA8831E

Page 2412 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 4) LAN-149 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 Case 15 Check steering angle sensor circuit. Refer to LAN-163, "Steering Angle Sensor Circuit Check" . PKIA

Page 2413 of 3371

INFINITI QX56 2004 Factory Service Manual LAN-150 [CAN] CAN SYSTEM (TYPE 4) Revision: August 20072004 QX56 Case 16 Check front air control circuit. Refer to LAN-164, "Front Air Control Circuit Check" . PKIA8127E PKIA8833E

Page 2414 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 4) LAN-151 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 Case 17 Check transfer control unit circuit. Refer to LAN-164, "Transfer Control Unit Circuit Check" . PKIA

Page 2415 of 3371

INFINITI QX56 2004 Factory Service Manual LAN-152 [CAN] CAN SYSTEM (TYPE 4) Revision: August 20072004 QX56 Case 18 Check ABS actuator and electric unit (control unit) circuit. Refer to LAN-165, "ABS Actuator and Electric Unit (Control Unit) C

Page 2416 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 4) LAN-153 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 Case 19 Check IPDM E/R circuit. Refer to LAN-165, "IPDM E/R Circuit Check" . PKIA8130E PKIA8836E
