Page 3273 of 3371

INFINITI QX56 2004 Factory Service Manual TF-148
CENTER CASE
Revision: August 20072004 QX56
FRONT DRIVE SHAFT AND DRIVE CHAIN
1. Install front drive shaft rear bearing, using Tool.
a. Install front drive shaft to front bearing, using Tool.
2.

Page 3274 of 3371

INFINITI QX56 2004 Factory Service Manual ASSEMBLY
TF-149
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: August 20072004 QX56
ASSEMBLYPFP:00030
Final AssemblyEDS00195
1. Install C-rings to mainshaft.
2. Set washer holder on mainshaft, and secure it with

Page 3275 of 3371

INFINITI QX56 2004 Factory Service Manual TF-150
ASSEMBLY
Revision: August 20072004 QX56
4. Install center case assembly to front case assembly.
CAUTION:
Pay careful attention so that mainshaft end is not damaged.
5. Tap center case lightly p

Page 3276 of 3371

INFINITI QX56 2004 Factory Service Manual ASSEMBLY
TF-151
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: August 20072004 QX56
10. Align the matchmark on front drive shaft with the mark on the
companion flange, then install the companion flange.
11. Inst

Page 3277 of 3371

INFINITI QX56 2004 Factory Service Manual TF-152
ASSEMBLY
Revision: August 20072004 QX56
15. Install air breather into rear case.
16. Apply specified Anaerobic Liquid Gasket or equivalent to entire
rear case mounting surface of center case as

Page 3278 of 3371

INFINITI QX56 2004 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS)
TF-153
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: August 20072004 QX56
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsEDS0031B
Inspection and Adjus

Page 3279 of 3371

INFINITI QX56 2004 Factory Service Manual TF-154
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: August 20072004 QX56
*: Always check with the Parts Department for the latest parts information.
Control Valve
Unit: mm (in)
*: Always check with

Page 3280 of 3371

INFINITI QX56 2004 Factory Service Manual WT-1
ROAD WHEELS & TIRES
E SUSPENSION
CONTENTS
C
D
F
G
H
I
J
K
L
M
SECTION WT
A
B
WT
Revision: August 20072004 QX56 PREPARATION ........................................................... 2
Special S

WT-1
ROAD WHEELS & TIRES
E SUSPENSION
CONTENTS
C
D
F
G
H
I
J
K
L
M
SECTION WT
A
B
WT
Revision: August 20072004 QX56 PREPARATION ........................................................... 2
Special Service Tool ................................................. 2
Commercial Service Tools ........................................ 2
NOISE, VIBRATION, AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 3
NVH Troubleshooting Chart ..................................... 3
WHEEL ....................................................................... 4
Inspection ................................................................. 4
WHEEL AND TIRE ASSEMBLY ................................. 5
Balancing Wheels .................................................... 5
REMOVAL ............................................................. 5
WHEEL BALANCE ADJUSTMENT ...................... 5
Rotation .................................................................... 6
LOW TIRE PRESSURE WARNING SYSTEM ............ 7
System Components ................................................ 7
System Description .................................................. 7
TRANSMITTER ..................................................... 7
REMOTE KEYLESS ENTRY RECEIVER ............. 7
BCM (BODY CONTROL MODULE) ...................... 8
LOW TIRE PRESSURE WARNING LAMP AND
BUZZER ................................................................ 8
DISPLAY UNIT ...................................................... 8
CAN COMMUNICATION ............................................ 9
System Description .................................................. 9
TROUBLE DIAGNOSES .......................................... 10
Wiring Diagram — T/WARN — .............................. 10
Terminal and Reference Value (BCM) .................... 12
ID Registration Procedure ...................................... 13
ID REGISTRATION WITH TRANSMITTER
ACTIVATION TOOL ............................................ 13
ID REGISTRATION WITHOUT TRANSMITTER
ACTIVATION TOOL ............................................ 14
Transmitter Wake Up Operation ............................. 15
............................................................................ 15
CONSULT-II Function (BCM) ................................. 16
Self-Diagnosis ........................................................ 17
DESCRIPTION .................................................... 17
FUNCTION .......................................................... 17CONSULT-II ......................................................... 17
How to Perform Trouble Diagnosis for Quick and
Accurate Repair ...................................................... 19
INTRODUCTION ................................................. 19
WORK FLOW ...................................................... 19
Preliminary Check .................................................. 20
Malfunction Code/Symptom Chart .......................... 21
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ........................................................................ 23
Inspection 1: Transmitter or Control Unit (BCM) ..... 23
MALFUNCTION CODE NO. 21, 22, 23 OR 24 ... 23
Inspection 2: Transmitter - 1 ................................... 23
MALFUNCTION CODE NO. 31, 32, 33, 34, 41,
42, 43, 44, 45, 46, 47 OR 48 ............................... 23
Inspection 3: Transmitter - 2 ................................... 24
MALFUNCTION CODE NO. 35, 36, 37 OR 38 ... 24
Inspection 4: Vehicle Speed Signal ........................ 25
MALFUNCTION CODE NO. 52 ........................... 25
TROUBLE DIAGNOSIS FOR SYMPTOMS .............. 26
Inspection 1: Low Tire Pressure Warning Lamp
Does Not Come On When Ignition Switch Is Turned
On ........................................................................... 26
Inspection 2: Low Tire Pressure Warning Lamp
Stays On When Ignition Switch Is Turned On ......... 26
Inspection 3: Low Tire Pressure Warning Lamp
Flashes When Ignition Switch Is Turned On .......... 28
Inspection 4: Hazard Warning Lamp Flashes When
Ignition Switch Is Turned On .................................. 29
Inspection 5: “TIRE PRESSURE” Information In
Display Unit Does Not Exist .................................... 30
Inspection 6: ID Registration Cannot Be Completed ... 30
REMOVAL AND INSTALLATION ............................. 31
Transmitter (Pressure Sensor) ............................... 31
REMOVAL ........................................................... 31
INSTALLATION ................................................... 31
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 33
Road Wheel ............................................................ 33
Tire ......................................................................... 33
