OPEL FRONTERA 1998 Workshop Manual 7A–116 AUTOMATIC TRANSMISSION (AW30-40LE) 252L100006 252L100007 252L100008 252ry00021 3. Snap ring Remove snap ring from clutch drum. 4. Flange, disc and plate Remove flange, two discs and two plate

Page 5898 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–117 252RY00022 252RY00023 252RY00024 252RY00025 10. Snap ring Remove snap ring. 11. Ring gear flange Remove ring flange from OD planetary ring gear. 13. Snap ri

Page 5899 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–118 AUTOMATIC TRANSMISSION (AW30-40LE) 252RY00026 252RY00027 252RY00028 252RY00029 15. OD one-way clutch Remove OD one-way clutch with outer race. INSPECTION AND REPAIR Check discs Using a microm

Page 5900 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–119 252L100009 252RY00031 Check OD direct clutch drum bushings Using a dial indicator, measure the inside diameter of the clutch drum bushings. If the

Page 5901 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–120 AUTOMATIC TRANSMISSION (AW30-40LE) REASSEMBLY 252L100010 Reassembly steps 1. Thrust washer 2. OD one-way clutch 3. Retaining plate 4. Snap ring 5. Race 6. Ring gear flange 7. Snap ring

Page 5902 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–121 252RY00032 252RY00033 252RY00026 252RY00024 Important operations 1. Thrust washer Install the thrust washer to the OD planetary gear, facing the gr

Page 5903 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–122 AUTOMATIC TRANSMISSION (AW30-40LE) 252RY00034 252RY00023 252RY00022 252RY00035 5. Race Coat the race with petroleum jelly and install it to the planetary gear. 6. Ring gear flange Install rin

Page 5904 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–123 252L100011 252L100012 252L100007 252L100013 9. O-ring Coat new O-rings with ATF and install them on the OD direct clutch piston. 10. OD direct clu
