OPEL FRONTERA 1998 Workshop Manual 7A–156 AUTOMATIC TRANSMISSION (AW30-40LE) 248RY00055 248RY00056 248RY00053 248RY00052 Important operations 1. Snap ring Install snap ring to planetary sun gear. 2. Sun gear input drum Place a wood

Page 5938 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–157 248RY00057 248RY00058 248RY00051 5. Thrust washer (plastic) Install thrust washer. NOTE: Make sure that the lugs fit into the holes on the sun

Page 5939 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–158 AUTOMATIC TRANSMISSION (AW30-40LE) SECOND BRAKE ASSEMBLY (B–2) DISASSEMBLY 246RY00006 Disassembly steps 1. Second brake assembly 2. Thrust washer (Plastic) 3. Snap ring 4. Spring retainer

Page 5940 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–159 246RY00007 247RY00001 246RY00008 247RY00034 Important operations 1. Second brake assembly Remove second brake assembly from output shaft. 2. Snap ring Plac

Page 5941 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–160 AUTOMATIC TRANSMISSION (AW30-40LE) REASSEMBLY 246RY00023 Reassembly steps 1. O–ring 2. Second brake piston 3. Piston sleeve 4. Piston retur n spring 5. Spring retainer 6. Snap ring 7

Page 5942 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–161 246RY00009 246RY00010 247RY00001 246RY00011 Important operations 1. O–ring Coat new O–ring with ATF and install them on the second brake piston. 2. Seco

Page 5943 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–162 AUTOMATIC TRANSMISSION (AW30-40LE) 246RY00012 246RY00014 7. Thrust washer (Plastic) Coat the thrust washer with petroleum jelly and install it to the second brake piston, with

Page 5944 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–163 REAR PLANETARY GEAR ASSEMBLY AND OUTPUT SHAFT DISASSEMBLY 247RY00027 Disassembly steps 1. Second brake assembly 2. Output shaft 3. Oil seal ring 4. Disc,
