Page 5857 of 6000
7A–76 AUTOMATIC TRANSMISSION (AW30-40LE)
249RY00010
249RY00008
NEUTRAL START SWITCH INSPECTION
Inspection
With a circuit tester, make a continuity test on the neutral star t
switch with the moving piece set in each position.
Continuity
Removal
Preparation:
Disconnect negative (–) battery cable.
1. Remove rear sound cover.
2. Remove the rear side ATF cooler pipe from the
transmission elbow.
3. Disconnect neutral star t switch connector.
4. Unstake the lock washer, and then remove the shaft nut.
5. Remove the neutral start switch.
Installation
To install, follow the removal steps in the reverse order, noting
the following points;
Adjustment
1) Loosen the neutral star t switch bolt and set the shift
selector to the "N" range.
2) Align the groove and neutral basic line.
3) Hold in position and tighten the bolt.Te r m i n a l
Po s i ti on143526879
P
R
N
D
2
L
Torque Nꞏm (kgꞏcm/lbꞏin)
Nut 7 (70/61)
Bolt 13 (130/113)
Page 5858 of 6000

AUTOMATIC TRANSMISSION (AW30-40LE) 7A–77
310RW020
F07RY00017
F07RY00018
BRAKE SIGNAL INSPECTION
Check that the brake light comes on when the brake pedal is
depressed.
VEHICLE SPEED SENSOR INSPECTION
1. Connect the Vehicle speed sensor connector terminal (1) to
the battery ( +) terminal and terminal (2) to the battery (-)
terminal.
2. Connect a resistance of 1.3k ohm to 5k ohm (1.4W or
more) between terminals (1) and (3).
NOTE:
Be extremely careful not to connect the battery (+) terminal
to the terminal (3)
This may damage the vehicle speed sensor.
3. Rotate the shaft of the vehicle speed sensor slowly and
measure the voltage at both ends with a digital tester.
Replace the sensor when the result of inspection is found
abnormal.
INPUT AND OUTPUT REVOLUTION
SENSOR INSPECTION
Use an ohmmeter to measure the resistance between
terminals 1 and 2.The voltage, with one rotation of shaft, fluctuates four
times in the following range: 10 to 14V
2V or less.
Standard resistance 560 – 680
(20C)
610 – 740
(40C)
Page 5859 of 6000
7A–78 AUTOMATIC TRANSMISSION (AW30-40LE)
F07RY00019
225RY00001
220RY00001
244RX00001
PATTERN SELECT SWITCH INSPECTION
Inspect that there is continuity between each terminals.
OVERDRIVE OFF SWITCH INSPECTION
Inspect that there is continuity between terminals 2 and 4.
SOLENOID INSPECTION
1. Resistance check
• Using an ohmmeter, check the resistance between each
terminals (S1/S2/SL) and body.
• Using an ohmmeter, check the resistance between
terminals (STH) and (STHG).
NOTE:
If the pressure contorl solenoid resistance is not within
specification, replace the valve body assembly.
2. Operation Check
Check the solenoid operation by blowing into an oil hole as
shown in the figure.
Solenoid S1 and S2 (Normal close type)
Solenoid S1, S2 and Lock-up
solenoid resistance11 - 15(20C)
12 - 16
(40C)
Pressure control solenoid
resistance5 - 5.6
(20C)
5.4 - 6.1
(40C)
When battery terminal is
disconnectedNo air leaks
When battery terminal is
connectedAir passes through
Page 5860 of 6000

AUTOMATIC TRANSMISSION (AW30-40LE) 7A–79
244RY00005
101RY00004
249RW003
242RW013
Look-up solenoid (Normal open type)
THROTTLE POSITION SENSOR
INSPECTION
1. Turn the starter switch to the "ON" position.
2. Measure the voltage between throttle position sensor
connector terminals 2 (output) and 3 (ground).
NOTE:
• Do not remove the sensor connector.
• Make sure that power source (4.75-5.25V) is measured
between terminals 1 and 3 before measurement at step
2).
ATF TEMPERATURE SENSOR
INSPECTION
1. Disconnect the front side ATF cooler pipe from the elbow
and remove the elbow.
2. Remove the ATF temperature sensor from the transmission
case.
3. Place the ATF temperature sensor in a container of ATF.
4. Measure the resistance between each terminals.
5. If either of the measured values exceeds the specified,
replace the ATF temperature sensor.
Nꞏm (kgꞏm/ lbꞏft)
When battery terminal is
disconnectedAir passes through
When battery terminal is
connectedNo air leaks
Throttle position Voltage (V)
Idle 0.25-0.45
WOT 3.74-4.56
Resistance 0.5 - 30 k
(0C - 120C)
Torque 15 (1.5/11)
Page 5861 of 6000
7A–80 AUTOMATIC TRANSMISSION (AW30-40LE)
256RY00001
256RW012
256RW013
SELECTOR LEVER
INSPECTION
1. Make sure that when the selector lever is shifted from "P" to
"L", a "clicking" can be felt at each shift position. Make sure
that the gear corresponds to that of the position plate
indicator.
2. Check to see if the shifter lever can be shifted as shown.
REMOVAL
Preparation:
Diconnect negative (–) battery cable.
1. Transfer Control Lever Knob
2. Front Console
Disconnect wiring harness connectors.
3. Selector Lever Assembly
1) Disconnect shift lock cable from the selector lever
assembly side.
2) Disconnect wiring harness connectors.
3) Disconnect shift control rod from the selector lever
assembly side.
Page 5862 of 6000

AUTOMATIC TRANSMISSION (AW30-40LE) 7A–81
256RW014
256RW015
INSTALLATION
To install, follow the removal steps in the reverse order, noting
the following points;
Adjustment of select lever and control rod
1) Place the vehicle on a level surface.
NOTE:
If the vehicle is not on a level surface, the shift select cable
set position will vary with the movement of the engine. To
prevent possible misadjustment of the cable, the vehicle
must be placed on a level surface.
2) Install the shift control rod (1) to the transfmission select
lever (2), and then place the lever in the "N" position.
3) Set select lever in the "N" position.
4) Push select lever forward and secure it (using a rubber
band (3), etc.) so that pin comes into contact with the wall
of detent plate.
5) Install the shift control rod (1) to the selector lever arm (4).
NOTE:
Do not apply to threaded portions.
6) After adjustment, operate select lever on a trial basis to
makes sure of its smooth operation and no abnormal
indication in each position.
Adjustment of shift lock cable
1) Set ignition key in "LOCK" position and selector lever in "P"
position.
2) Adjust cable screw cap on selector lever side to provide a
gap (slack for cable) of 1–2mm between rod on steering
lock side and stopper.
Adjust cap as follows:
a. Pull screw cap (1) in arrow direction to put off slack of
inner cable.
b. With cable kept as (a), adjust gap between nut (2) and
bracket to 5mm (0.2in).
c. Lock inner cable by tur ning nut (3) while holding nut (2) in
place.
NOTE:
Clean the rod threads and do not apply oil to the threaded
portions.Nꞏm(kgꞏm / lbꞏft)
Nut torque 32 (3.3/24)
Nꞏm(kgꞏcm / lbꞏin)
Lock nut torque 3.7 (38/33)
Page 5863 of 6000
7A–82 AUTOMATIC TRANSMISSION (AW30-40LE)
3) Make sure of proper operation of shift lock through checks
as follows:
a. Selector lever shall not be moved out of "P" position with
ingition key in "Lock" position.
b. Selector lever can be moved out of "P" position with
ignition key in "ON" position only when brake pedal is
depressed.
c. Ignition key can be turned to "LOCK" position only when
selector lever is in "P" position (key can be pulled out).
If (a) and (c) fail, readjust cable. If (b) fails, readjust
connector wiring and brake pedal switch.
Page 5864 of 6000
AUTOMATIC TRANSMISSION (AW30-40LE) 7A–83
826RY00005
826RY00006
249RY00011
249RY00012
TRANSMISSION CONTROL MODULE
(TCM)
REMOVAL
Preparation:
Disconnect negative (–) battery cable.
1. Disconnect the TCM harness connectors.
2. Remove fixing nuts (3 pieces) and TCM from the bracket.
INSTALLATION
To install, follow the removal steps in reverse order.
SHIFT SOLENOID AND LOCK-UP
SOLENOID
REMOVAL
Preparation:
• Disconnect negative (–) battery cable.
• Remove the rear sound cover.
• Drain the fluid.
Refer to
"ATF REPLACEMENT" in this section.
1. Remove the nineteen bolts and oil pan.
2. Remove the oil strainer assembly.
3. Disconnect the solenoid wiring connectors from the shift
solenoid S1(1), S2(2) and lock-up solenoid (3).
4. Remove each retaining bolts and solenoids.
INSTALLATION
To install, follow the removal steps in reverse order noting the
following point;
Tprque Nꞏm (kgꞏcm/lbꞏin)
Solenoid S1, S2 bolt 7 (70/61)
Lock-up solenoid bolt 10 (100/87)
