Circuit Breaker
The circuit breaker is a protective device designed to
open the circuit when a current load is in excess of rated
breaker capacity. If there is a short or other type of
overload condition in the circuit, the excessive current will
open the circuit between the circuit breaker terminals.
The reset knob (1) pops out when the circuit is open. Push
the reset knob in place to restore the circuit after repairing
it.
Relay
Battery and load location may require that a switch be
placed some distance from either component. This
means a longer wire and a higher voltage drop (1).
The installation of a relay between the battery and the
load reduces the voltage drop (2).
Because the switch controls the relay, amperage through
the switch can be reduced.
LOAD
12LOAD
RELAY
D08RW404
1
Page 2610 of 6000
Relay Specifications and Configurations
* Relay contact shown in the wiring diagram indicates condition before actuation.
Page 2611 of 6000
Diode – Diode Specifications and Configurations
Diode – Maximum Rating (Temp. = 77°F (25°C))
Items Rating Remarks
Peak reverse voltage 400V
Transient peak reverse voltage 500V
Average output current 1.5A Temp. = 104°F (40°C)
Working ambient temperature –22°F~176°F (–30°C~80°C)
Storage temperature –40°F~212°F (–40°C~100°C)
Page 2612 of 6000
Connector
The connector pin shape (2) determines whether the
connector is male (3) or female (1).
The symbol illustrated in the figure is used as connector,
in the circuit of this section.
Legend
(4) Female Side Connector
(5) Male Side ConnectorConnector is identified with a connector number (6)
The applicable terminal number (7) is shown for each
connector.
6
7
4
5
12 3
Page 2613 of 6000

Connector terminal numbers (10) are clearly shown.
Male side connector (9) terminal numbers are in
sequence from upper right to lower left.
Female side connector (8) terminal numbers are in
sequence from upper left to lower right.
NOTE:
1. For those connectors on which specific terminal
numbers or symbols are shown (such as PCM), the
terminal numbers or symbols are used in the circuit
diagram, irrespective of the above rule.
Refer to the following figure.2. The connectors used for relays have their own terminal
number assignment, irrespective of the above rule.
Refer to the following figure.
Double Lock Type Connector
Double lock type yellow color connectors are used for
supplemental restraint system–air bag circuit. When
removing the cable harness, disconnect the connector by
unlocking at two places, outside (1) and inside (2). In such
a case, do not pull the cables. Otherwise, cable
disconnection may occur.
When connecting the connector, insert the connector
completely and lock at outside. Imperfect locking may
cause malfunction of SRS system circuit.
1234
56781 2 3 4
5 6 7 8
10 8
9
C1C2C3C4C5C6C7C8C9C10C11C12C13C14C15C16D1D2D3D4D5D6D7D8D9D10D11D12D13D14D15D162
1
24
136 5
65
1423
Page 2614 of 6000
Reading the Circuit Diagram
In this section, each system has its own parts location
illustration and circuit diagram.
And harness connector faces used in the circuit diagram
are shown at the end of this section.
Parts Location
The parts location shows the location of the connectors
(1) and the harness (2) used in each harness routing.
12
D08RWB11
Page 2615 of 6000
Circuit Diagram
The circuit diagram shows the power supply (1), the load
or loads (2) and the grounding point(s) (3).
5.0
W BATT.(+)
C-17 15A
RR DEF
RR DEFOGGER RELAY
3.0
L/O
3.0
B/L
3.0
B/L
3.0
B/L
B-38
4
I-17
5I-17
ILLUMINATION
CONTROLLER(3)
RR DEFOGGER
SW
RR DEFOGGER
2
H-37
G-7
1 2
B-38
2
2
H-31
1
G-3
3.0
B/Y
0.5
L/W
0.5
L/W
0.5
L/W 0.5
O/L
0.5
O/L STARTER SW
(IG1)
C-4 10A
ELEC.IGN.
3
B-38
4
I-17
15
H-48TIMER6
I-17 0.85
G/R TAIL RELAY(4)
B-38
1
H-253
H-255
1
I-17
B-2 2.0
B 3.0
B 3.0
B
2.0
B 0.3
B0.3
R/G
BODY-RHR-3
BODY-RR4
H-37
1
2
3
D08RW425
Page 2616 of 6000
Harness Connector Faces
The harness connector faces show each connector’s
number (1), configuration (2) and the pin number (3).
No.
B-21Connector face No. Connector face
B-22
B-23
NOT USED NOT USED
12 3B-31
B-32
B-33
D08RW424
