7A–188 AUTOMATIC TRANSMISSION (AW30-40LE)
248RY00014
248RY00019
248RY00020
247RY00012
7. Snap ring
Install the snap ring.
Check pack clearance of second brake
Using a thickness gauge, measure the clearance between
the snap ring and flange as shown in the figure.
If the values are nonstandard, check for an improper
installation.
8. Drum
While turning the sun gear input drum clockwise, install it
into the one-way clutch.
NOTE:
Confirm the thrust washers are installed correctly.
9. Front planetary gear and bearing
Install the front planetary gear to the sun gear.
NOTE:
Confirm the bearing and race is installed correctly.mm (in.)
Clearance0.62–1.98
(0.0244–0.0780)
Page 5970 of 6000
AUTOMATIC TRANSMISSION (AW30-40LE) 7A–189
247RY00013
248RY00017
247RY00014
248RY00010
With wooden blocks under the output shaft, stand the
transmission on the output shaft.
10. Snap ring
Using snap ring pliers, install the snap ring.
11. Race
Coat the bearing race with petroleum jelly and install it onto
the front planetary gear.
12. Second coast brake band
Insert the second coast brake band to the case. Bearing race diameter (Reference) mm (in.)
Bearing race Diameter
Inside 34.3 (1.350)
Outside 47.8 (1.882)
Page 5971 of 6000
7A–190 AUTOMATIC TRANSMISSION (AW30-40LE)
248RY00021
248RY00022
248RY00023
247RY00015
13. E–ring and pin
Install the pin through the brake band.
Install the E–ring to the pin.
14. Bearing and race
Coat the bearing and race with petroleum jelly and install
them onto the forward clutch.
15. Race
Coat the race with petroleum jelly and install it onto the
front planetary ring gear. Bearing and race diameter (Reference) mm (in.)
Inside Outside
Bearing 26.0 (1.024) 46.7 (1.839)
Race 26.0 (1.024) 48.9 (1.925)
Race diameter (Reference) mm (in.)
Inside Outside
Race 26.8 (1.055) 47.0 (1.850)
Page 5972 of 6000
AUTOMATIC TRANSMISSION (AW30-40LE) 7A–191
247RY00016
247RY00017
247RY00019
247RY00018
Align the flukes of the discs in the forward clutch.
16. Front planetary ring gear
Align the spline of th front planetary gear with the flukes of
the discs and install the front planetary gear to the forward
clutch.
17. Bearing and race
Coat the bearing and race with petroleum jelly and install
them onto the ring gear.
18. Direct clutch and forward clutch
Install the assembled direct clutch, forward clutch and front
planetary ring gear into the transmission case. Bearing and race diameter (Reference) mm (in.)
Inside Outside
Bearing 32.6 (1.283) 47.7 (1.878)
Race 30.6 (1.205) 53.6 (2.110)
Page 5973 of 6000

7A–192 AUTOMATIC TRANSMISSION (AW30-40LE)
248RY00024
248RY00025
248RY00026
248RY00027
Using vernier calipers, measure the distance between the
sun gear input drum and direct clutch drum as shown in the
figure.
If the values are nonstandard, check for an improper
installation.
Coat the assembled bearing and race with petroleum jelly
and install it onto the forward clutch.
19. Second coast brake piston assembly
Coat the oil seal ring with ATF and install it to the second
coast brake piston.
Install the washer, spring and piston to the piston rod.
Install the E–ring.
(1): Second coast brake piston
(2): Oil seal
(3): Piston rod
20. Snap ring
Coat two new oil seals with ATF and install them to the
piston cover.
Install the spring, second coast brake piston assembly and
piston cover to the case.
Using snap ring pliers, install the snap ring.mm (in.)
Height9.8 – 11.8
(0.386 – 0.465)
Assembled bearing and race diameter (Reference)
mm (in.)
Inside Outside
Bearing
and race33.7 (1.327) 47.8 (1.882)
Page 5974 of 6000
AUTOMATIC TRANSMISSION (AW30-40LE) 7A–193
248RY00005
248RY00004
252RY00007
252RY00005
Check piston stroke of second coast brake
Place a mark on the second coast brake piston rod as
shown in the figure.
Using wire gage, measure the stroke by applying the
compressed air (4–8kg/cm
2, 57–114 psi or 392–785kPa)
as shown in the figure.
If the values are nonstandard, check for an improper
installation.
21. Race
Coat the race with petroleum jelly and install it onto the
overdrive suppor t assembly.
22. OD support
Aim the bolt and oil holes of the overdrive suppor t toward
the valve hole side, and align them with the bolt hole of the
transmission case and insert.mm (in.)
Piston stroke1.5–3.0
(0.059–0.118)
Race diameter (Reference) mm (in.)
Inside Outside
Race 36.8 (1.450) 50.9 (2.004)
Page 5975 of 6000
7A–194 AUTOMATIC TRANSMISSION (AW30-40LE)
252RY00008
252RY00004
247RY00020
252RY00009
23. Snap ring
Using snap ring pliers, install the snap ring as shown in the
figure.
Install and tighten the two bolts.
Check end of output shaft
Using a dial indicator, measure the end play of the output
shaft by hand.
24. Flange, plate and disc
Install the (flat ring) 4.0 mm (0.157 in.) thick flange with the
rounded edge side of the flange facing the disc.
Alternately install four discs and three plates. (Disc first)Nꞏm(kgꞏm / lbꞏft)
Torque 25 (2.6/19)
mm (in.)
End play0.27–0.86
(0.0106–0.0339)
Page 5976 of 6000
AUTOMATIC TRANSMISSION (AW30-40LE) 7A–195
246RY00001
252RY00003
244RY00001
246RY00001
25. Snap ring
Install the (stepped ring) flange with the flat side of the
flange facing the disc.
Install the snap ring.
Check piston stroke of overdrive brake
Place a dial indicator onto the overdrive brake piston as
shown in the figure.
Measure the stroke by applying and releasing the
compressed air (4–8kg/cm
2, 57–114–psi or 392–785 kPa)
as shown in the figure.
If the values are nonstandard, select another flange.
Remove the snap ring. Snap ring (Reference) mm (in.)
Inside diameter 167.9 (6.61)
mm (in.)
Piston stroke1.40–1.70
(0.0551–0.0670)
Available Flange size mm(in.)
3.3 (0.130) 3.8 (0.150)
3.5 (0.138) 3.9 (0.154)
3.6 (0.142) 4.0 (0.158)
3.7 (0.146)
