OPEL FRONTERA 1998 Workshop Manual 8D–400 WIRING SYSTEM
ITEM MALFUNCTION POSSIBLE CAUSE DETECTING METHOD REMARKS
Even when door
unlocked with
key, alarm
operates.
Alarm does not
operate even with
tailgate open.
Even when
tailgate is

Page 2994 of 6000

OPEL FRONTERA 1998 Workshop Manual WIRING SYSTEM 8D–401
STEP OPERATION ITEM TO BE CHECKEDITEM OF
REMARKS
MALFUNCTION
Be sure to lock door
with locking knob.
Activate alarm
device.
All doors are
unlocked.
With key set at unlock
positi

Page 2995 of 6000

OPEL FRONTERA 1998 Workshop Manual 8D–402 WIRING SYSTEM
STEP OPERATION ITEM TO BE CHECKEDITEM OF
REMARKS
MALFUNCTION
With key set at
unlock position,
check to see if
alarm stops. (All
doors are unlocked.)
All doors are
locked.
Activa

Page 2996 of 6000

OPEL FRONTERA 1998 Workshop Manual WIRING SYSTEM 8D–403
STEP OPERATION ITEM TO BE CHECKEDITEM OF
REMARKS
MALFUNCTION
Only right rear door
is unlocked.
With key at unlock
position, check to
see if alarm stops.
(With all doors
unlocked

Page 2997 of 6000

OPEL FRONTERA 1998 Workshop Manual 8D–404 WIRING SYSTEM
STEP OPERATION ITEM TO BE CHECKEDITEM OF
REMARKS
MALFUNCTION
Activate alarm
device. Check to see if indicator light
goes off after about 10 seconds.
Check to see if alarm operat

Page 2998 of 6000

OPEL FRONTERA 1998 Workshop Manual WIRING SYSTEM 8D–405
TERMINAL
CONNECTIONCHECK
OPERATIONCIRCUIT
NO. ITEM CONDITION
1 FRT door switch–LH, RH ContinuityOpen door Continuity
Close door No continuity
2 RR door switch–LH, RH Continu

Page 2999 of 6000

OPEL FRONTERA 1998 Workshop Manual 8D–406 WIRING SYSTEM
There are four kinds of ID codes which can be registered,
for which these three modes, ID code new registration, ID
code additional registration and ID code check, are
ava

Page 3000 of 6000

OPEL FRONTERA 1998 Workshop Manual WIRING SYSTEM 8D–407
Step Action Yes No
The control unit makes lock/unlock response once with interval of
one second.
Is the response complete?
The control unit makes lock/unlock response thre

WIRING SYSTEM 8D–407
Step Action Yes No
The control unit makes lock/unlock response once with interval of
one second.
Is the response complete?
The control unit makes lock/unlock response three times with
interval of one second.
Is the response complete? 12
13Finished
Finished—
—
Step Action Yes No
1. Open the driver’s side door.
2. Turn the starter switch off.
Is the action complete?
Turn the starter switch to ACC position and then off three times
within five seconds after step 1.
Is the action complete within five seconds?
Close the door and then open it two times within ten seconds after
step 2.
Is the action complete within ten seconds?
1. Turn the starter switch to ACC position and then off three
times.
2. Close the door and then open it.
NOTE: This step must be performed within ten seconds after step
3.
Is the action complete?
The control unit makes lock/unlock response two times with
interval of one second.
Is the response complete?
Operate the lock or unlock button of transmitter within twenty
seconds after step 5.
Is the action complete?
The control unit makes lock/unlock response two times with
interval of one second as ID temporary registration.
Is the response complete?
Operate the lock or unlock transmitter within twenty seconds after
step 7.
Is the action complete?
The control unit compares temporary registered ID code with
receiving ID code.
Is temporary registered ID code the same as receiving ID code?
The control unit makes lock/unlock response three times with
interval of one second.
Is the response complete?
The control unit registers new ID code.
Is the registration complete? 1
2
3
4
5
6
7
8
9
10
11Go to Step 2
Go to Step 3
Go to Step 4
Go to Step 5
Go to Step 6
Go to Step 7
Go to Step 8
Go to Step 9
Go to Step 11
Finished
Go to Step 12—
Finished
Finished
Finished
—
Finished
—
Finished
Go to Step 10
—
Go to Step 13
This procedure additionally registers a new received ID
code with holding registered ID codes. When total
number of registered ID codes and newly registered ID
code exceeds four, they are erased in order of older one.
