Page 5929 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–148 AUTOMATIC TRANSMISSION (AW30-40LE) 248RY00041 248RY00040 248RY00048 11. Snap ring Install the snap ring with a screw driver. Be sure the end gap of the snap ring is not aligned wit

Page 5930 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–149 248RY00039 248RY00038 Install direct clutch assembly to forward clutch assembly Align the flukes of discs in the direct clutch. Install the direct clutch

Page 5931 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–150 AUTOMATIC TRANSMISSION (AW30-40LE) FRONT PLANETARY GEAR DISASSEMBLY 247RY00022 247RY00021 INSPECTION AND REPAIR Check front planetary ring gear bushing Using a dial indicator, measure the ins

Page 5932 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–151 REASSEMBLY 247RY00045 Reassembly steps 1. Thrust bearing and race 2. Race (Metal) 3. Thrust bearing and race 4. Race

Page 5933 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–152 AUTOMATIC TRANSMISSION (AW30-40LE) 247RY00023 247RY00024 247RY00025 247RY00026 Important operations 1. Thrust bearing and race Coat the races and bearing with petroleum jelly. Install the rac

Page 5934 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–153 PLANETARY SUN GEAR AND NO.1 ONE–WAY CLUTCH DISASSEMBLY 248RY00050 Disassembly steps 1. One–way clutch and second brake hub 2. Thrust washer (Plastic) 3

Page 5935 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–154 AUTOMATIC TRANSMISSION (AW30-40LE) 248RY00051 248RY00052 248RY00053 248RY00054 Important operations Check operation of No.1 one–way clutch Hold the planetary sun gear and turn the s

Page 5936 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–155 REASSEMBLY 248RY00066 Reassembly steps 1. Snap ring 2. Sun gear input drum 3. Snap ring 4. Oil seal ring (Metal) 5. Thrust washer (Plastic) 6. One–w
