OPEL FRONTERA 1998 Workshop Manual 4A2B–18DIFFERENTIAL (REAR 244mm) 4. Set the dial indicator 5–8840–0126–0 to “0”. Place it on the mounting post of the gauging arbor with the contact button touching the indicator pad

Page 4026 of 6000

OPEL FRONTERA 1998 Workshop Manual DIFFERENTIAL (REAR 244mm) 4A2B–19 8. Select the shim thickness using the chart; Pinion marking Dial indicator reading (inches)+10+9+8+7+6+5+4+3+2+10–1–2–3–4–5–6–7–8–9–10 0.0802.1

Page 4027 of 6000

OPEL FRONTERA 1998 Workshop Manual 4A2B–20DIFFERENTIAL (REAR 244mm) 4. Place the shim (1) on the drive pinion, then install the inner bearing (2) onto the pinion by using installer 5–8840–2574–0 and a press . NOTE: Do

Page 4028 of 6000

OPEL FRONTERA 1998 Workshop Manual DIFFERENTIAL (REAR 244mm) 4A2B–21 4. Using punch 5–8840–2293–0, stake the flange nut at two points. NOTE: When staking, be sure to turn the nut to ensure that there is no change in bea

Page 4029 of 6000

OPEL FRONTERA 1998 Workshop Manual 4A2B–22DIFFERENTIAL (REAR 244mm) 4. Adjust feeler gauge thickness from side to side until ring gear backlash is in the specified range. Backlash: 0.13– 0.2mm (0.005– 0.008in) 425RS032With

Page 4030 of 6000

OPEL FRONTERA 1998 Workshop Manual DIFFERENTIAL (REAR 244mm) 4A2B–23 16. Tighten the bolt to the specified torque. Torque:108Nꞏm (11.0kgꞏm/80 lb ft) 425RS036 Gear Tooth Contact Pattern Check and Adjustment 1. Apply a thin coat of

Page 4031 of 6000

OPEL FRONTERA 1998 Workshop Manual 4A2B–24DIFFERENTIAL (REAR 244mm) Differential Cage Assembly Disassembled View 415RY00001 Legend (1) Pinion Mate Gear (2) Thrust Washer(for Side Gear) (3) Side Gear (4) Differential Shaft(5) Ring Gea

Page 4032 of 6000

OPEL FRONTERA 1998 Workshop Manual DIFFERENTIAL (REAR 244mm) 4A2B–25 Disassembly 1. Remove bolt. 2. Remove ring gear. 3. Remove lock pin using a small drift. 425RY00002 4. Remove the differential shaft by using a hard metal r
