6A – 52 ENGINE MECHANICAL
TIMING GEAR
REMOVAL
1. Loosen fixing bolt for generator and remove
generator assembly.
2. Remove fixing nuts, then remove cooling fan
assembly and fan pulley.
3. Remove crankshaft damper pulley.
4. Belt cover
1) Disconnect harness connector of CMP
(camshaft position) sensor.
2) Remove CMP sensor.
3) Remove belt cover.
5. Loosen belt tensioner to remove timing belt.
6. Remove camshaft pulley.
7. Remove high pressure oil pump pulley.
8. Remove front plate.
9. Remove vacuum pump.
10. Remove power steering pump.
11. Remove gear cover assembly.
12. Idle gear A.
1) Set two bolts to sub gear of idle gear A and turn
it to align the tooth of idle gear A then lock them
by bolt as show in the illustration.
2) Remove idle gear A fixing bolts.
3) Remove idle gear A.Legend
(1) Sub-Gear
(2) Main Gear
(3) Bar
(4) Locking Bolt
2
3
4
5 8
7
6 91
020RW028
Legend
(1) Idle Gear A
(2) High Pressure Oil Pump Gear
(3) Vacuum Pump Gear
(4) Power Steering Pump Gear(5) Balance Gear LH
(6) Idle Gear C
(7) Crankshaft Gear
(8) Balance Gear RH
(9) Idle Gear B
4 1
2
3
014RW177
Page 1786 of 6000
ENGINE MECHANICAL 6A – 53
Legend
(1) Bolt
(2) Retainer
(3) Idle Gear A
(4) Idle Gear A Shaft
(5) Align Mark
(6) Crankshaft Gear
(7) O-Ring
13. Idle gear C
1) Use the special tool on idle gear C, turning the
sub gear to align the teeth, then set lock pin.
2) Remove idle gear C fixing bolt then remove the
idle gear C with flange.
Camshaft Gear Tool : 5-8840-2591-0
Legend
(1) Lock pin
(2) Camshaft Gear ToolLegend
(1) Bolt
(2) Retainer
(3) Idle Gear C
(4) Idle Gear C Shaft
(5) Align Mark
(6) Align Mark
(7) Idle Gear A
(8) Balance Shaft Gear LH
(9) Timing Mark
14. Idle gear B
1) Loosen idle gear B fixing bolt to remove idle
gear B with flange.
Legend
(1) Bolt
(2) Retainer
(3) Idle Gear B
(4) Idle Gear B Shaft
(5) Align Mark
3
6
5
4
3
2
1 7 1
7
014R200007
1
2
014RW181
12345 56
6 8
8 37
7
9
99
014RW175
35
5
4
3
2
1
014R200008
Page 1787 of 6000

6A – 54 ENGINE MECHANICAL
15. High pressure oil pump
1) Remove oil pump gear fixing bolt then remove
oil pump.
Legend
(1) O-Ring
(2) High Pressure Oil Pump Gear
(3) Bolt
(4) Timing Mark
16. Remove balance shaft gear LH. and RH.
17. Remove crankshaft gear.
INSTALLATION
1. Crankshaft gear
1) Force key into the crankshaft and insert
crankshaft gear with the crankshaft gear key
groove set on the key.Legend
(1) Crankshaft Gear Installer
(2) Crankshaft Gear
2. Balance shaft gear
1) Install the balance shaft gear RH to balance
shaft, tighten center bolt to the specified torque.
Torque : 32 Nꞏm (3.2 kgꞏm/23 lb ft)
2) Install thrust plate for balance shaft LH before
installing the balance shaft gear LH.
Torque : 25 Nꞏm (2.5 kgꞏm/18 lb ft)
3) Install balance shaft gear LH to balance shaft,
tighten center bolt to the specified torque.
Torque : 32 Nꞏm (3.2 kgꞏm/23 lb ft)
Legend
(1) Center Bolt
(2) Plate
(3) Balance Shaft Gear RH
(4) Timing Mark
4
GEAR:O/PUMP
IDLE GEAR A
1
2
3
040RW005
12
2
012RW066
3
4 2
1
014RW173
Page 1788 of 6000

ENGINE MECHANICAL 6A – 55
3. Idle gear A
1) Insert idle gear A shaft to align alignment mark
between idle gear A shaft and timing gear case.
2) Apply engine oil to the shaft surface.
3) Install the idle gear A to align the timing mark
with the crankshaft gear.
4) Install the flange, tighten bolts to the specified
torque.
Torque: 25 Nꞏm (2.5 kgꞏm/18 lb ft)
Legend
(1) Bolt
(2) Retainer
(3) Idle Gear A
(4) Idle Gear A Shaft
(5) Align Mark
(6) Crankshaft Gear
(7) O-Ring
NOTE: Conform not difference timing marks between
each others.
4. Idle gear C
1) Insert idle gear C shaft to align alignment mark
between idle gear C shaft and timing gear case.
2) Apply engine oil to the shaft surface.
3) Align timing mark on idle gear C with balance
shaft gear LH and idle gear A timing marks, then
insert idle gear C.
4) Set position of idle gear C flange with a dowel
pin, tighten bolt to the specified torque.
Torque: 25 Nꞏm (2.5 kgꞏm/18 lb ft)Legend
(1) Bolt
(2) Retainer
(3) Idle Gear C
(4) Idle Gear C Shaft
(5) Align Mark
(6) Align Mark
(7) Idle Gear A
(8) Balance Shaft Gear LH
(9) Timing Mark
5. Idle gear B
1) Insert idle gear B shaft to align alignment mark
between idle gear B shaft and timing gear case.
2) Apply engine oil to the shaft surface.
3) Align timing mark on idle gear B with balance
shaft gear RH and crankshaft gear timing marks,
then insert idle gear B.
4) Install flange and tighten the bolt to the specified
torque.
Torque: 51 Nꞏm (5.2 kgꞏm/38 lb ft)
3
6
5
4
3
2
1 7 1
7
014R200007
12345 56
6 8
8 37
7
9
99
014RW175
Page 1789 of 6000

6A – 56 ENGINE MECHANICAL
Legend
(1) Bolt
(2) Retainer
(3) Idle Gear B
(4) Idle Gear B Shaft
(5) Align Mark
6. High pressure oil pump
1) Install O-ring on the high pressure oil pump.
2) Install the high pressure oil pump to the timing
gear case, tighten the nut to the specified
torque.
Torque: 20 Nꞏm (2.0 kgꞏm/14.5 lb ft)
NOTE: Be sure to set O-ring completely.
Legend
(1) O-ring (large)
(2) High pressure oil pump
(3) Nut
(4) O-ring (small)7. High pressure oil pump
1) Install O-ring on the oil pump shaft with grease
and install the gear with the idle gear A timing
mark set at the oil pump gear timing mark.
2) Tighten center bolt to the specified torque.
Torque: 75 Nꞏm (7.6 kgꞏm / 55 lb ft)
NOTE: Be sure to align timing marks with each other.
Legend
(1) O-ring
(2) High Pressure Oil Pump Gear
(3) Center Bolt
(4) Timing Mark
8. Remove lock from idle gear.
1) Remove lock bolt from idle gear A and remove
lock pin from idle gear C.
9. Timing gear case assembly
1) Clean fixing surface of timing gear case.
2) Install the gasket on the idle gear rear side end.
3) Apply liquid gasket to the timing gear case fitting
surface.
NOTE: Be sure to apply liquid gasket evenly.
4) Install timing gear case and tighten bolts to the
specified torque.
Torque: 20 Nꞏm (2.0 kgꞏm / 14.5 lb ft)
NOTE: Must install within 5 minutes after applying liquid
gasket.
35
5
4
3
2
1
014R200008
1
2
43
040RW007
4
GEAR:O/PUMP
IDLE GEAR A
1
2
3
040RW005
Page 1790 of 6000
ENGINE MECHANICAL 6A – 57
10. Vacuum pump
1) Install vacuum pump and tighten bolts to
specified torque.
Torque: 25 Nꞏm (2.5 kgꞏm / 18 lb ft)
2) Install noise insulator cover.
11. Power steering pump (P/S)
1) Install P/S pump.
Torque: 25 Nꞏm (2.5 kgꞏm / 18 lb ft)12. Install front plate.
Torque: 20 Nꞏm (2.0 kgꞏm / 14.5 lb ft)
13. High pressure oil pump pulley.
1) Install oil pump pulley and tighten to specified
torque.
Torque:10 Nꞏm (1.0 kgꞏm / 7.2 lb ft)
2
2~2.5mm
2~2.5mm
Apply liquid gasket around inside
of the bolt hole
Bolt hole
Inside
Outside
F06HX00001
052RW001
430RW017
012RW035
Page 1791 of 6000

6A – 58 ENGINE MECHANICAL
14. Camshaft pulley
1) Align TDC mark with crankshaft pulley and gear
case cover.
2) Set camshaft stopper on the end of intake and
exhaust camshaft.
Camshaft Stopper: 5-8840-2592-0
3) Install key to camshaft and install camshaft
pulley.
4) Apply engine oil to camshaft pulley fixing bolt
and tighten bolt with angular tightening method.
First step: 40 Nꞏm (4.0 kgꞏm / 29 lb ft)
Second step: 60° to 90°
15. Timing belt
1) Install tensioner and tighten the bolt temporarily.
2) Align timing mark with camshaft pulley timing
mark and timing gear case timing mark.
3) Set No.1 cylinder TDC position.4) Install the timing belt in the following order
camshaft pulley, oil pump pulley, tensioner.
NOTE:
1) It is recommended for easy installation that the belt
be secured with a double clip after it is installed to
each pulley.
2) The “ISUZU” mark should be read from the front of
the engine when installing the timing belt.
5) Install the belt tensioner.
6) Conform not phase difference each pulley.
7) Tension the timing belt with two turns of the
crankshaft.
8) Tighten the tensioner bolt in order A to B to the
specified torque.
Torque: Bolt A 5 Nꞏm (0.5 kgꞏm/3.6 lb ft)
Bolt B 2 Nꞏm (0.2 kgꞏm/1.4 lb ft)
Legend
(1) Align Mark
(2) Camshaft Pulley
(3) Timing Belt
(4) Oil Pump Pulley
(5) Bolt B
(6) Tensioner Assy
(7) Tensioner Bolt A
(8) Tensioner Spring
16. CMP sensor bracket
1) Install CMP sensor bracket and tighten bolt to
the specified torque.
Torque: 20 Nꞏm (2.0 kgꞏm / 14.5 lb ft)
17. Timing belt cover
1) Install timing belt cover and tighten bolt to the
specified torque.
Torque: 9 Nꞏm (0.9 kgꞏm / 6.5 lb ft)
2) Tighten CMP sensor to the specified torque.
Torque: 9 Nꞏm (0.9 kgꞏm / 6.5 lb ft)
012RW036
012RW099
1
2
3
8
67
4 5
F06RW055
Page 1792 of 6000
ENGINE MECHANICAL 6A – 59
18. Crankshaft damper pulley
1) Insert damper pulley with the crankshaft key
groove set on the key.
2) Tighten damper pulley bolt to the specified
torque.
Torque: 220 Nꞏm (22 kgꞏm / 159 lb ft)19. Cooling fan Assembly
1) Install the cooling fan assembly to the fan pulley,
tighten the nuts to the specified torque.
Torque: 8 Nꞏm (0.8 kgꞏm / 5.8 lb ft)
20. AC generator drive belt.
1) Temporarily tighten generator fixing bolts and
belt tensioner adjustment plate.
2) Tension the generator drive belt then tighten the
generator fixing bolt.
Torque: 40 Nꞏm (4.0 kgꞏm / 29 lb ft)
3) Tighten the belt tensioner adjustment plate bolt.
Torque: 20 Nꞏm (2.0 kgꞏm / 14.5 lb ft)
