Page 441 of 6000

OPEL FRONTERA 1998 Workshop Manual DIFFERENTIAL (FRONT) 4A1–4 3. Remove the front propeller shaft. Refer to Front Propeller Shaft in this section. 4. Remove flange nut by using pinion flange holder 5–8840–2157–0.

Page 442 of 6000

OPEL FRONTERA 1998 Workshop Manual 4A1–5 DIFFERENTIAL (FRONT) Front Drive Axle Assembly Front Drive Axle Assembly and Associated Parts 412RW001 Legend (1) Mounting Bolt and Nut (2) Washer and Spacer (3) Breather Hose (with Shift on t

Page 443 of 6000

OPEL FRONTERA 1998 Workshop Manual DIFFERENTIAL (FRONT) 4A1–6 3. Remove the drain bolt to drain differential oil. NOTE: a. During the work, be sure that the diff case is supported by the jack. 412RS003 b. Remove the brake

Page 444 of 6000

OPEL FRONTERA 1998 Workshop Manual 4A1–7 DIFFERENTIAL (FRONT) 16. Remove mounting bolt and nut. 412RS004 17. Remove washer and spacer. 18. Remove the mounting bracket fixing bolt. 412RS005 19. Lower the vehicle and disconnect the RH

Page 445 of 6000

OPEL FRONTERA 1998 Workshop Manual DIFFERENTIAL (FRONT) 4A1–8 5. Tighten the mounting bolt and nut to the specified torque. Torque: 152 Nꞏm (15.5kgꞏm/112 lb ft) 412RW005 Legend (1) Frame (2) Spacer (3) Washer (4) Bolt (5)

Page 446 of 6000

OPEL FRONTERA 1998 Workshop Manual 4A1–9 DIFFERENTIAL (FRONT) Differential Assembly Disassembled View 415RW001 Legend (1) Differential Assembly (2) Flange Nut (3) Flange (4) Dust Cover (5) Oil Seal (6) Outer Bearing (7) Outer Bearin

Page 447 of 6000

OPEL FRONTERA 1998 Workshop Manual DIFFERENTIAL (FRONT) 4A1–10 3. Using holding fixture 5–8840–0275–0 and holding fixture base 5–8840–0003–0, fix the differential assembly to the bench. 425RW046 4. Remove bearin

Page 448 of 6000

OPEL FRONTERA 1998 Workshop Manual 4A1–11 DIFFERENTIAL (FRONT) 13. Remove the drive pinion assembly using a soft metal rod and a hammer. 425RW041 14. Remove collapsible spacer. 15. Remove the inner bearing using a separator 5
