Page 3761 of 6000

OPEL FRONTERA 1998 Workshop Manual 871RY00014

Page 3762 of 6000

OPEL FRONTERA 1998 Workshop Manual

Page 3763 of 6000

OPEL FRONTERA 1998 Workshop Manual 871RX020

Page 3764 of 6000

OPEL FRONTERA 1998 Workshop Manual 871RX013

Page 3765 of 6000

OPEL FRONTERA 1998 Workshop Manual Legend (1) Drive Plate Bolt (2) Drive Plate (3) Snap Ring(4) Pulley Assembly (5) Field Coil (6) Shim(s) (7) Lead Wire Removal 1. Remove drive plate bolt by using drive plate holder J-7624 (1) to preve

Page 3766 of 6000

OPEL FRONTERA 1998 Workshop Manual 3. Remove shim(s). 4. Remove snap ring (1) by using snap ring pliers. 5. Remove pulley assembly by using pulley puller pilot J-38424 (2), pulley puller J-8433 (1) and pulley puller leg J-24092-

Page 3767 of 6000

OPEL FRONTERA 1998 Workshop Manual Inspection and Repair Drive Plate If the frictional surface shows signs of damage due to excessive heat, the drive plate and pulley should be replaced. Pulley Assembly Check the app

Page 3768 of 6000

OPEL FRONTERA 1998 Workshop Manual 7. Install drive plate bolt by using drive plate holder J-7624 (1) to prevent the drive plate from rotating. Tighten the drive plate bolt to the specified torque. Torque: 13 Nꞏm (113 lb in)
