OPEL FRONTERA 1998 Workshop Manual 6E–204 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS Installation Procedure 1. Install the IAT sensor into the grommet in the intake air duct. 035RW056 2. Correct the IAT electrical connector. 3. Conn

Page 2098 of 6000

OPEL FRONTERA 1998 Workshop Manual 6E–205 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS Installation Procedure 1. Install the MAP sensor and bolts on the intake manifold. Torque: 4 Nꞏm (35 lb in) 035RW057 2. Connect the MAP s

Page 2099 of 6000

OPEL FRONTERA 1998 Workshop Manual 6E–206 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS 3. Disconnect the electrical connector from the OT sensor. 4. Remove the OT sensor. 035RW061 Installation Procedure 1. Install the OT sensor.

Page 2100 of 6000

OPEL FRONTERA 1998 Workshop Manual 6E–207 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS damage, therefore, it is important to use care when handling and testing electronic components. NOTE: To prevent possible Electrostatic

Page 2101 of 6000

OPEL FRONTERA 1998 Workshop Manual 6E–208 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS Installation Procedure 1. Install the ECM. 035RW092 2. Install the bolts, ECM bracket and battery bracket. 035RW094 3. Connect the ECM connector. 0

Page 2102 of 6000

OPEL FRONTERA 1998 Workshop Manual 6E–209 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS 2. Remove the cover of the intercooler. 035RW051 3. Remove the bolts and the left side bracket to the intercooler. 4 . R e m o v e t h e

Page 2103 of 6000

OPEL FRONTERA 1998 Workshop Manual 6E–210 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS Vehicle Speed Sensor (VSS) Removal Procedure CAUTION: The VSS is located on the right side of the transfer case just ahead of the re

Page 2104 of 6000

OPEL FRONTERA 1998 Workshop Manual 6E–211 4JX1–TC ENGINE DRIVEABILITY AND EMISSIONS 5. Connect the negative battery cable. Air Cleaner/Air Filter Removal Procedure 1. Loosen the clamp between the air cleaner lid and the duct. 2. Re
