OPEL FRONTERA 1998 Workshop Manual 7A–60 AUTOMATIC TRANSMISSION (AW30-40LE)

Page 5842 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–61

Page 5843 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–62 AUTOMATIC TRANSMISSION (AW30-40LE) 826RY00018 F07RY00024 MANUAL SHIFTING TEST NOTE: With this test, it can be determined whether the trouble lies within the electrical circuit or is a mechanic

Page 5844 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–63 F07RY00002 STALL TEST The object of this test is to check the overall performance of the transmission and engine by measuring the maximum engine speed

Page 5845 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–64 AUTOMATIC TRANSMISSION (AW30-40LE) F07RY00003 TIME LAG TEST If the shift lever is shifted while the engine is idling, there will be a cer tain time elapse or lag before the shock can be felt.

Page 5846 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–65 F07RY00004 HYDRAULIC TEST PREPARATION 1) Warm up the transmission fluid. 2) Remove the transmission case test plug and mount the hydraulic pressure gauge. Oi

Page 5847 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–66 AUTOMATIC TRANSMISSION (AW30-40LE) 255RT004 F07RY00005 F07RY00006 ROAD TEST NOTE: Perform the test at normal operation fluid temperature (50 – 80 C or 122 – 176F). "D" RANGE TES

Page 5848 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–67 F07RY00007 F07RY00008 F07RY00009 F07RY00010 3) Run at "D" range lock-up or OD gear and check for abnormal noise and vibration. NOTE: The
