OPEL FRONTERA 1998 Workshop Manual 7A–172 AUTOMATIC TRANSMISSION (AW30-40LE) 247RY00043 246RY00016 247RY00002 246RY00016 Important operations 1. Thrust bearing and race Remove assembled bearing and race from transmission case.

Page 5954 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–173 246RY00017 247RY00044 6. Reaction sleeve Insert special tool behind the reaction sleeve and gradually lift it out of the transmission case. Reaction sleeve

Page 5955 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–174 AUTOMATIC TRANSMISSION (AW30-40LE) REASSEMBLY 246RY00025 Reassembly steps 1. O–ring 2. O–ring 3. 1st and reverse brake piston No.1 4. O–ring 5. Reaction sleeve 6. 1st and reverse

Page 5956 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–175 246RY00018 246RY00019 246RY00020 246RY00021 Important operations 1. O–ring Coat three new O–rings with ATF. Install the two O–ring on the No.1 piston.

Page 5957 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–176 AUTOMATIC TRANSMISSION (AW30-40LE) 247RY00002 246RY00022 247RY00043 8. Snap ring Set special tool as shown, and compress the return spring with special tool. Spring compressor : 5–8840–02

Page 5958 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–177 TRANSMISSION CASE DISASSEMBLY 249RY00001 Disassembly steps 1. Spacer 2. Pin 3. Manual valve lever shaft 4. Manual valve lever 5. Oil seal 6. Oil seal

Page 5959 of 6000

OPEL FRONTERA 1998 Workshop Manual 7A–178 AUTOMATIC TRANSMISSION (AW30-40LE) 249RY00002 249RY00003 249RY00004 240RY00021 Important operations 1. Spacer Using a chisel, cut off the spacer and remover it from the shaft. 2. P

Page 5960 of 6000

OPEL FRONTERA 1998 Workshop Manual AUTOMATIC TRANSMISSION (AW30-40LE) 7A–179 REASSEMBLY 249RX00001 Reassembly steps 1. Oil seal 2. Oil seal 3. Spacer 4. Manual valve lever 5. Manual valve lever shaft 6. Pin
