Page 2137 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Fuse Case Test Bulb
Short [A]
SW1
Short [B]
Relay
Light
Short [C]
SW2 SolenoidDisconnect
Disconnect DisconnectTo Ignition SW
IG Terminal
INTRODUCTION±HOW TO PERFORM FOR SYSTEM INSPECTION
A±7
8
Wire

Page 2138 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Push
Equal Amperage Rating
A±8
INTRODUCTION±CIRCUIT PROTECTION
9
Wire Harness Repair Manual (RM1022E)
CIRCUIT PROTECTION
All electrical circuits are protected against excessive loads which might oc

Page 2139 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Equal Amperage Rating
Equal Amperage Rating
Puller
INTRODUCTION±CIRCUIT PROTECTION
A±9
10
Wire Harness Repair Manual (RM1022E)
REPLACEMENT OF FUSE AND FUSIBLE LINK
HINT: If replacing the fuse or f

Page 2140 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Reference:
(mm)
B±1
TERMINAL AND CONNECTOR REPAIR±PREPARATORY ITEMS
11
Wire Harness Repair Manual (RM1022E)
PREPARATORY ITEMS
Crimping tool AMP Part No. 169060For caulking
press sleeves
ToolSpecial

Page 2141 of 2543

TOYOTA SUPRA 1995 Service Repair Manual TERMINAL AND CONNECTOR REPAIR±CONNECTOR REPAIR
B±2
12
Wire Harness Repair Manual (RM1022E)
CONNECTOR REPAIR
The repair parts now in supply are limited to those connectors having common shapes and te

TERMINAL AND CONNECTOR REPAIR±CONNECTOR REPAIR
B±2
12
Wire Harness Repair Manual (RM1022E)
CONNECTOR REPAIR
The repair parts now in supply are limited to those connectors having common shapes and terminal
cavity numbers. Therefore, when there is no available replacement connector of the same shape or
terminal cavity number, please use one of the alternative methods described below. Make sure that the
terminals are placed in the original order in the connector cavities, if possible, to aid in future diagnosis.
1. When a connector with a different number of terminals
than the original part is used, select a connector
having more terminal cavities than required, and replace both the male and female connector parts.
EXAMPLE: You need a connector with six terminals, but the only replacement available is a connector
with eight terminal cavities. Replace both the male and female connector parts with the eight terminal part,
transferring the terminals from the old connectors to the new connectors.
2. When several different type terminals
are used in one connector, select an appropriate male and female
connector part for each terminal type used, and replace both male and female connector parts.
EXAMPLE: You need to replace a connector that has two different types of terminals in one connector.
Replace the original connector with two new connectors, one connector for one type of terminal, another
connector for the other type of terminal.
3. When a different shape of connector
is used, first select from available parts a connector with the
appropriate number of terminal cavities, and one that uses terminals of the same size as, or larger than,
the terminal size in the vehicle. The wire lead on the replacement terminal must also
be the same size as,
or larger than, the nominal size of the wire in the vehicle. (ºNominalº size may be found by looking at the
illustrations in the section F or by direct measurement across the diameter of the insulation). Replace all
existing terminals with the new terminals, then insert the terminals into the new connector.
EXAMPLE: You need to replace a connector that is round and has six terminal cavities. The only round
replacement connector has three terminal cavities. You would select a replacement connector that has
six or more terminal cavities and is not round, then select terminals that will fit the new connector. Replace
the existing terminals, then insert them into the new connector and join the connector together.
B

Page 2142 of 2543

TOYOTA SUPRA 1995 Service Repair Manual B±3
TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT
13
Wire Harness Repair Manual (RM1022E)
TERMINAL REPLACEMENT
These steps must be followed when replacing a terminal.
Step 1. Identify the conne

Page 2143 of 2543

TOYOTA SUPRA 1995 Service Repair Manual TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT
B±4
14
Wire Harness Repair Manual (RM1022E)
Step 1. Identify the connector and the terminal type.
Confirm whether the connector you require is the

Page 2144 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Example:
Back of the
Connector Body
P/N 90980±10854
B±5
TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT
15
Wire Harness Repair Manual (RM1022E)
NOTICE:
When the terminal used is gold plated, b
