WATER VALVE
WATER VALVE REMOVAL
1. REMOVE HEATER RADIATOR
(See page AC±82)
2. REMOVE WATER VALVE
(a) Remove the 2 screws.
(b) Remove the water valve from heater radiator.
WATER VALVE INSTALLATION
1. INSTALL WATER VALVE
(a) Install the water valve to heater radiator.
(b) Install the 2 screws.
2. INSTALL HEATER RADIATOR
± AIR CONDITIONING SYSTEMWATER VALVEAC±97
Page 98 of 2543
EXPANSION VALVE
ON±VEHICLE INSPECTION
1. CHECK QUANTITY OF GAS DURING REFRIGERATION
CYCLE
2. INSTALL MANIFOLD GAUGE SET
3. RUN ENGINE
Run the engine at 1,500 rpm for at least 5 minutes. Then
check that the high pressure reading is 1.371.57 MPa (14±16
kgf/cm
2, 199±228 psi).
4. CHECK EXPANSION VALVE
If the expansion valve is faulty, the low pressure reading will
drop to 0 kPa (0 kgf/cm
2, 0 psi).
HINT: When the low pressure drops to 0 kPa (0 kgf/cm
2, 0
psi), feel the receiver's IN and OUT sides for zero tempera-
ture difference.
EXPANSION VALVE REMOVAL
1. REMOVE EVAPORATOR
(See page AC±82)
2. REMOVE EXPANSION VALVE
Using a hexagon wrench, remove the 2 bolts and separate
the evaporator and expansion valve.
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
INSTALLATION HINT: Lubricate the new O±ring with com-
pressor oil and install the tubes.
EXPANSION VALVE INSTALLATION
Installation is in the reverse order of removal. AC±98
± AIR CONDITIONING SYSTEMEXPANSION VALVE
Page 99 of 2543
BLOWER MOTOR
BLOWER MOTOR REMOVAL
1. REMOVE GLOVE BOX AND SIDE AIR DUCT
(a) Remove the glove box.
(See page BO±45)
(b) Remove the 5 bolts and the brace.
(c) Remove the side air duct.
2. REMOVE SCUFF PLATE
(See page BO±44)
3. REMOVE FLOOR CARPET
4. REMOVE ECM COVER
Remove the 2 nuts and the ECM cover.
5. REMOVE BLOWER MOTOR
(a) Disconnect the connector.
(b) Remove the 3 screws and the blower motor.
BLOWER MOTOR INSPECTION
(See page AC±61)
BLOWER MOTOR INSTALLATION
Installation is in the reverse order of removal.
± AIR CONDITIONING SYSTEMBLOWER MOTORAC±99
Page 100 of 2543
BLOWER MOTOR CONTROL RELAY
BLOWER MOTOR CONTROL RELAY
REMOVAL
1. REMOVE BLOWER MOTOR
(See page AC±82)
2. REMOVE BLOWER MOTOR CONTROL RELAY
(a) Disconnect the connector.
(b) Remove the 3 screws and the blower motor control relay.
BLOWER MOTOR CONTROL RELAY
INSPECTION
(See page AC±61)
BLOWER MOTOR CONTROL RELAY
INSTALLATION
Installation is in the reverse order of removal. AC±100
± AIR CONDITIONING SYSTEMBLOWER MOTOR CONTROL RELAY
Page 101 of 2543
SERVOMOTOR
AIR INLET SERVOMOTOR REMOVAL
1. REMOVE INSTRUMENT PANEL
(See page BO±45)
2. REMOVE AIR INLET SERVOMOTOR
(a) Disconnect the connector.
(b) Disconnect the control link.
(c) Remove the 3 screws and the air inlet servomotor.
AIR INLET SERVOMOTOR INSPECTION
(See page AC±47)
AIR INLET SERVOMOTOR
INSTALLATION
Installation is in the reverse order of removal.
AIR MIX SERVOMOTOR REMOVAL
1. REMOVE INSTRUMENT PANEL
(See page BO±45)
2. REMOVE AIR MIX SERVOMOTOR
(a) Remove the defroster duct.
(b) Remove the 3 screws and the water valve cover.
(c) Disconnect the connector.
(d) Disconnect the control link.
(e) Remove the 2 screws and the air mix servomotor.
AIR MIX SERVOMOTOR INSPECTION
(See page AC±47)
AIR MIX SERVOMOTOR INSTALLATION
Installation is in the reverse order of removal.
± AIR CONDITIONING SYSTEMSERVOMOTORAC±101
Page 102 of 2543
AIR OUTLET SERVOMOTOR REMOVAL
1. REMOVE INSTRUMENT PANEL
(See page BO±45)
2. REMOVE AIR OUTLET SERVOMOTOR
(a) Disconnect the connector.
(b) Remove the 3 screws and the air outlet servomotor.
AIR OUTLET SERVOMOTOR
INSPECTION
(See page AC±51)
AIR OUTLET SERVOMOTOR
INSTALLATION
Installation is in the reverse order of removal. AC±102
± AIR CONDITIONING SYSTEMSERVOMOTOR
Page 103 of 2543

PRESSURE SWITCH
PRESSURE SWITCH REMOVAL
1. DISCHARGE REFRIGERANT IN REFRIGERATION
SYSTEM
2. REMOVE PRESSURE SWITCH
(a) Disconnect the connector.
(b) Remove the pressure switch from the liquid tube.
HINT: Lock the pressure switch mount on the tube with an
open end wrench, being careful not to deform the tube, and
remove the switch.
PRESSURE SWITCH INSPECTION
(See page AC±41)
PRESSURE SWITCH INSTALLATION
1. INSTALL PRESSURE SWITCH
(a) Install the pressure switch to the liquid tube.
Torque: 10 NVm (100 kgfVcm, 7 ftVlbf)
HINT: Lock the switch mount on the tube with an open end
wrench, being careful not to deform the tube, and install the
switch.
(b) Connect the connector.
2. EVACUATE AIR IN REFRIGERATION SYSTEM AND
CHARGE WITH REFRIGERANT
Specified amount:
700 + 50 g (24.96 + 1.76 oz.)
3. INSPECTION FOR LEAKAGE OF REFRIGERANT
Using a gas leak tester, check for leakage of refrigerant from
the pressure switch.
4. INSPECT A/C OPERATION
± AIR CONDITIONING SYSTEMPRESSURE SWITCHAC±103
Page 104 of 2543
SENSOR
REVOLUTION DETECTING SENSOR
REMOVAL
1. REMOVE COMPRESSOR
(See page AC±86)
2. REMOVE REVOLUTION DETECTING SENSOR
Remove the 2 bolts and the revolution detecting sensor.
Torque: 6.0 NVm (60 kgfVcm, 52 in.Vlbf)
REVOLUTION DETECTING SENSOR
INSPECTION
(See page AC±39)
REVOLUTION DETECTING SENSOR
INSTALLATION
Installation is in the reverse order of removal.
SOLAR SENSOR REMOVAL
1. REMOVE INSTRUMENT PANEL
(See page BO±45)
2. REMOVE SOLAR SENSOR
Disconnect the harness and pull the solar sensor upward
from instrument panel.
SOLAR SENSOR INSPECTION
(See page AC±36)
SOLAR SENSOR INSTALLATION
Installation is in the reverse order of removal.
ROOM TEMPERATURE SENSOR
REMOVAL
1. REMOVE CENTER CLUSTER PANEL
(See page BO±45)
2. REMOVE ROOM TEMPERATURE SENSOR
(a) Disconnect the connector.
(b) Remove the aspirator hose.
(c) Remove the 2 screws and the room temperature sensor. AC±104
