DIAGNOSTIC TROUBLE CODE CHART
HINT: Parameters listed in the chart may not be exactly the same as your reading due to type of the instruments
or other factors.
DTC
No.
Number of
MIL BlinksCircuitDiagnostic Trouble Code Detecting Condition
Normal
G, NE Signal
(No.1)
G, NE Signal
(No.2)
Ignition Signal
A/T Control
Signal
No code is recorded
No ªNEº or ªG1º and ªG2º signal to ECM for 2 sec. or more after
cranking
No NE signal to ECM for 0.1 sec. or more at 1,000 rpm or
more
NE signal does not pulse 12 times to ECM during the interval
between G1 and G2 pulses
Deviation in G (G1, G2) and NE signal continues for 3 sec. dur-
ing idling (throttle fully closed) after engine warmed up
No IGF signal to ECM for 4~7 consecutive IGT signals with en-
gine speed less than 3,000 rpm
Fault in communications between the engine CPU and A/T CPU
in the ECM
EG±494± ENGINE2JZ±GTE ENGINE TROUBLESHOOTING
Page 2002 of 2543

If a malfunction code is displayed during the diagnostic trouble code check in test mode, check the circuit for
that code listed in the table below (Proceed to the page given for that circuit).
Trouble Area
Malfunction
Indicator
Lamp*
1
Memory*2
See page
Trouble Area
Normal
Mode
Test
Mode
Memory
See page
±
±
±
±
±
Open or short in crankshaft position sensor, camshaft
position sensor No.1, No.2 circuit
Crankshaft position sensor
Camshaft position sensor No.1, No.2
Starter
ECM
ON
N.A.
EG±515
Open or short in crankshaft position sensor circuit
Crankshaft position sensor
ECM
ON
N.A.
Open or short in crankshaft position sensor circuit
Mechanical system malfunction (skipping teeth of
timing belt, belt stretched)
Crankshaft position sensor
ECM
N.A.
ON
EG±518
Mechanical system malfunction (skipping teeth of
timing belt, belt stretched)
Camshaft position sensor No.1, No.2
ECM
ON
N.A.
Open or short in IGF circuit from igniter to ECM
Igniter
ECM
ON
N.A.
EG±519
ECM
ON
N.A.
X
EG±524
*1, 2: See page EG±502.
± ENGINE2JZ±GTE ENGINE TROUBLESHOOTINGEG±495
