Page 1577 of 2543

TOYOTA SUPRA 1995 Service Repair Manual MAS AIR FLOW (MAF) METER COMPONENTS FOR REMOVAL AND INSTALLATION MAF METER REMOVAL Installation is in the reverse order of removal. 1. REMOVE NO.1 AIR HOSE 2. REMOVE AIR CLEANER HOSE 3. REMOVE MAF

Page 1578 of 2543

TOYOTA SUPRA 1995 Service Repair Manual MAF METER INSPECTION 1. INSPECT MAF METER RESISTANCE Using an ohmmeter, measure the resistance between termi- nals THA and E2.     Between terminals

Page 1579 of 2543

TOYOTA SUPRA 1995 Service Repair Manual THROTTLE BODY ON±VEHICLE INSPECTION Throttle Body INSPECT THROTTLE BODY (a) Check that the throttle linkage moves smoothly. (b) Check the vacuum at the purge port. wStart the engine. wCheck the vac

Page 1580 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Throttle Opener 1. WARM UP ENGINE Allow the engine to warm up to normal operating tempera- ture. 2. CHECK IDLE SPEED Idle speed (Transmission in neutral position): 650 + 50 rpm 3. CHECK THROTTLE OP

Page 1581 of 2543

TOYOTA SUPRA 1995 Service Repair Manual THROTTLE BODY REMOVAL Installation is in the reverse order of removal. 1. DRAIN ENGINE COOLANT 2. REMOVE THROTTLE BODY (a) Disconnect the hose, cables and connectors from the throttle body: (1) Ai

Page 1582 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Throttle Position Sensor 1. INSPECT THROTTLE POSITION SENSOR (a) Disconnect the throttle opener vacuum hose from the throttle body. (b) Apply vacuum to the throttle opener. (c) Insert a 0.54 mm (

Page 1583 of 2543

TOYOTA SUPRA 1995 Service Repair Manual (d) Gradually turn the sensor clockwise until the ohmmeter deflects, and secure it with the 2 set screws. (e) Recheck the continuity between terminals IDL and E2.

Page 1584 of 2543

TOYOTA SUPRA 1995 Service Repair Manual 3. INSPECT SUB±THROTTLE VALVE Check that there is no clearance between the throttle stop screw and throttle valve gear when the subthrottle valve is ful- ly closed. 4. INSPECT SUB±THROTTLE POSITIO
