TOYOTA SUPRA 1995 Service Repair Manual PARK/NEUTRAL POSITION SWITCH REPLACEMENT 1. REMOVE FRONT EXHAUST PIPE (See page EG±83) 2. DISCONNECT PARK/NEUTRAL POSITION SWITCH CONNECTOR 3. REMOVE PARK/NEUTRAL POSITION SWITCH (a) Remove the co

Page 402 of 2543

TOYOTA SUPRA 1995 Service Repair Manual VALVE BODY REMOVAL Installation is in the reverse order of removal. INSTALLATION HINT: After installation, fill A/T fluid and check fluid level. (See page AT1±42) 1. RAISE VEHICLE AND CLEAN TRANSMISS

Page 403 of 2543

TOYOTA SUPRA 1995 Service Repair Manual 4. WHEN REPLACING 3 SOLENOIDS (a) Disconnect the connectors from the solenoids. (b) Remove the solenoid mounting bolts. Torque: 10 NVm (100 kgfVcm, 7 ftVlbf) (c) Remove the solenoids. 5. REMOVE O

Page 404 of 2543

TOYOTA SUPRA 1995 Service Repair Manual 7. DISCONNECT CONNECTORS FROM EACH SOLENOID 8. REMOVE VALVE BODY (a) Remove the 17 bolts. Torque: 10 NVm (100 kgfVcm, 7 ftVlbf) INSTALLATION HINT: Each bolt length is indicated in the il- lustration

Page 405 of 2543

TOYOTA SUPRA 1995 Service Repair Manual PARKING LOCK PAWL REMOVAL Installation is in the reverse order of removal. 1. REMOVE VALVE BODY (See page AT1±16) 2. REMOVE PARKING LOCK PAWL BRACKET INSTALLATION HINT: w Push the lock rod fully fo

Page 406 of 2543

TOYOTA SUPRA 1995 Service Repair Manual 2. REMOVE VALVE BODY (See page AT1±16) 3. PUSH THROTTLE CABLE OUT OF TRANSMISSION CASE Remove the retaining bolt and pull out the throttle cable. 4. INSTALL THROTTLE CABLE Install the retaining bolt

Page 407 of 2543

TOYOTA SUPRA 1995 Service Repair Manual EXTENSION HOUSING REMOVAL Installation is in the reverse order of removal. INSTALLATION HINT: After installation, fill A/T fluid and check fluid lever. (See page AT1±42) 1. RAISE VEHICLE AND POSITIO

Page 408 of 2543

TOYOTA SUPRA 1995 Service Repair Manual ASSEMBLY REMOVAL AND INSTALLATION Remove and install the part, as shown. AT1±22± AT340E (2JZ±GE) AUTOMATIC TRANSMISSIONASSEMBLY REMOVAL AND INSTALLATION
