Page 1153 of 2543
SERVICE SPECIFICATIONS
SERVICE DATA
Firing order ± 1 ± 5 ± 3 ± 6 ± 2 ± 4
High±tension
cord
Resistance Limit
25 k per cord
Spark plug
Recommended spark plug ND
NGK
Correct electrode gap for new plug
Maximum electrode gap for used plug
PK16R11
BKR5EP11
1.1 mm (0.043 in.)
1.3 mm (0.051 in.)
Ignition coil
Primary coil resistance at cold
at hot
Secondary coil resistance at cold
at hot
0.36±0.55
0.45±0.65
9.0±15.4 k
11.4±18.1 k
Distributor
Air gap
Pickup coil resistance at cold G1±G
G2±G
NE±G
at hot G1±G
G2±G
NE±G
0.2±0.5 mm (0.008±0.020 in.)
125±200
125±200
155±250
160±235
160±235
190±290
TORQUE SPECIFICATIONS
Part tightened NVm kgfVcm ftVlbf
Spark plug x Cylinder head 18 180 13
IG±18± IGNITION SYSTEM2JZ±GE
Page 1154 of 2543
(2JZ±GTE)
PRECAUTION
1. With a tachometer connected to the system, connect the
tester probe of the tachometer to terminal IG of the
DLC1.
2. With a timing light connected to the system, connect the
tester probe to the green wire of the igniter
3. As some tachometers are not compatible with this
ignition system, we recommend that you confirm the
compatibility of your unit before use.
4. Never allow the tachometer terminals to touch ground as
it could result in damage to the igniter and/or ignition
coil.
5. Do not disconnect the battery while the engine is
running.
6. Check that the igniter is properly grounded to the body.
± IGNITION SYSTEM2JZ±GTEIG±19
Page 1155 of 2543
PREPARATION
SST(SPECIAL SERVICE TOOLS)
09240±00020Wire Gauge Set
RECOMMENDED TOOLS
09082±00050TOYOTA Electrical Tester Set
09200±00010Engine Adjust Kit
EQUIPMENT
Megger insulation resistance meter Spark plug
Spark plug cleaner
Thermometer
IG±20± IGNITION SYSTEM2JZ±GTE
Page 1156 of 2543

ON±VEHICLE INSPECTION
SPARK TEST
CHECK THAT SPARK OCCURS
(a) Remove the ignition coil. (See ignition coil removal)
(b) Remove the spark plug.
(c) Install the spark plug to the ignition coil, and connect the
ignition coil connecter.
(d) Ground the spark plug.
(e) Check if spark occurs while engine is being cranked.
HINT: To prevent gasoline from being injected from injectors
during this test, crank the engine for no more than 1±2 se-
conds at time.
If the spark does not occur, do the test as follows:
SPARK TEST
CHECK CONNECTION OF IGNITION COIL, IGNITER
CHECK POWER SUPPLY TO IGNITION COIL AND
IGNITER
1. Turn ignition switch to ON.
2. Check that there is battery voltage at
ignition coil positive (+) terminal.
CHECK RESISTANCE OF IGNITION COIL(See page IG±23)Resistance: Cold Hot
Primary 0.54 ± 0.84 0.68 ± 0.98
CHECK RESISTANCE OF CAMSHAFT AND
CRANKSHAFT POSITION SENSOR
(See page IG±24)Resistance: Cold Hot
NIPPONDENSO 835 ± 1,400 1,060 ± 1,645
AISAN 985 ± 1,600 1,265 ± 1,890
CHECK IGT SIGNAL FROM ECM(See page EG±519)
TRY ANOTHER IGNITER
Connect securely.
Check wiring between ignition switch
to ignition coil and igniter.
Replace the ignition coil.
Replace the camshaft and crankshaft position
sensor.
Check wiring between ECM,and igniter, and
then try another ECM.
ADJUST IGNITION TIMING
(See ignition timing inspection and adjustment)
± IGNITION SYSTEM2JZ±GTEIG±21
Page 1157 of 2543

SPARK PLUGS INSPECTION
NOTICE:
wNever use a wire brush for cleaning.
wNever attempt to adjust the electrode gap on used a spark
plug.
wSpark plugs should be replaced every 100,000 km (60,000
miles).
1. REMOVE IGNITION COILS ASSEMBLIES
(See ignition coils removal)
2. INSPECT ELECTRODE
Using a megger (insulation resistance meter), measure the
insulation resistance.
Standard correct insulation resistance:
10 M or more
If the resistance is less than specified, proceed to step 4.
HINT: If a megger is not available, the following simple meth-
od of inspection provides fairly accurate results.
Simple Method:
(a) Quickly race the engine 5 times to 4,000 rpm.
(b) Remove the spark plug.
(c) Visually check the spark plug.
If the electrode is dry...OK
If the electrode is wet...Proceed to step 4
(d) Reinstall the spark plug.
3. REMOVE SPARK PLUGS
4. VISUALLY INSPECT SPARK PLUGS
Check the spark plug for thread damage and insulator dam-
age.
If abnormal, replace the spark plug.
Recommended spark plug:
ND
PK20R11
NGK
BKR6EP11
5. INSPECT ELECTRODE GAP
Maximum electrode gap for used spark plug:
1.3 mm (0.051 in.)
Correct electrode gap for new spark plug:
1.1 mm (0.043 in.)
NOTICE: If adjusting the gap of a new spark plug, bend only
the base of the ground electrode. Do not touch the tip. Never
attempt to adjust the gap on the used plug.
IG±22± IGNITION SYSTEM(2JZ±GTE)
Page 1158 of 2543

6. CLEAN SPARK PLUGS
If the electrode has traces of wet carbon, allow it to dry and
then clean with a spark plug cleaner.
Air pressure:
Below 588 kPa (6 kgf/cm
2, 85 psi)
Duration:
20 seconds or less
HINT: If there are traces of oil, remove it with gasoline before
using the spark plug cleaner.
7. REINSTALL SPARK PLUGS
Torque: 18 NVm (180 kgfVcm, 13 ftVlbf)
8. REINSTALL IGNITION COILS ASSEMBLIES
(See ignition coils installation)
IGNITION COIL INSPECTION
NOTICE: ºColdº and ºHotº in the following sentences express
the temperature of the coils themselves. ºColdº is from ±105C
(145F) to 505C (1225F) and ºHotº is from 505C (1225F) to 1005C
(2125F).
1. REMOVE NO.3 TIMING BELT COVER
2. DISCONNECT IGNITION COIL CONNECTORS
3. INSPECT PRIMARY COIL RESISTANCE
Using an ohmmeter, measure the resistance between the
positive (+) and negative (±) terminals.
Primary coil resistance:
Cold
0.54 ± 0.84
Hot
0.68 ± 0.98
If the resistance is not as specified, replace the ignition coil.
4. RECONNECT IGNITION COIL CONNECTORS
5. REINSTALL NO.3 TIMING BELT COVER
± IGNITION SYSTEM(2JZ±GTE)IG±23
Page 1159 of 2543
CAMSHAFT POSITION SENSORS
INSPECTION
NOTICE: ºColdº and ºHotº in the following sentences express
the temperature of the sensors themselves. ºColdº is from
±105C (145F) to 505C (1225F) and ºHotº is from 505C (1225F) to
1005C (2125F).
1. DISCONNECT CAMSHAFT POSITION SENSOR
CONNECTORS
2. INSPECT CAMSHAFT POSITION SENSOR RESISTANCE
Using an ohmmeter, measure the resistance between termi-
nals.
Resistance:
Cold
NIPPONDENSO
835±1,400
AISAN
985±1,600
Hot
NIPPONDENSO
1,060±1,645
AISAN
1,265±1,890
If the resistance is not as specified, replace the camshaft
position sensor.
3. RECONNECT CAMSHAFT POSITION SENSOR
CONNECTORS IG±24
± IGNITION SYSTEM(2JZ±GTE)
Page 1160 of 2543
CRANKSHAFT POSITION SENSOR
INSPECTION
NOTICE: ºColdº and ºHotº in the following sentences express
the temperature of the sensors themselves. ºColdº is from
±105C (145F) to 505C (1225F) and ºHotº is from 505C (1225F) to
1005C (2125F).
1. REMOVE NO.2 AIR TUBE FOR CAC
2. DISCONNECT CRANKSHAFT POSITION SENSOR
CONNECTOR
3. INSPECT CRANKSHAFT POSITION SENSOR
RESISTANCE
Using an ohmmeter, measure the resistance between termi-
nals.
Resistance:
Cold
NIPPONDENSO
835±1,400
AISAN
985±1,600
Hot
NIPPONDENSO
1,060±1,645
AISAN
1,265±1,890
If the resistance is not as specified, replace the crankshaft
position sensor.
4. RECONNECT CRANKSHAFT POSITION SENSOR
CONNECTOR
5. REINSTALL NO.2 AIR TUBE FOR CAC
IGNITER INSPECTION
(See procedure Spark Test on page IG±22)
± IGNITION SYSTEM(2JZ±GTE)IG±25
