TOYOTA SUPRA 1995 Service Repair Manual TERMINAL AND CONNECTOR REPAIR±TERMINAL REPLACEMENT B±46 56 Wire Harness Repair Manual (RM1022E) NOTICE: If you working on the waterproof type, make sure that a rubber plug or a terminal gasket is in

Page 2186 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Lever Lever B±47 TERMINAL AND CONNECTOR REPAIR±HOW TO INSTALL AND REMOVE SPECIAL CONNECTORS 57 Wire Harness Repair Manual (RM1022E) HOW TO INSTALL AND REMOVE SPECIAL CONNECTORS Low Fit and Lever Typ

Page 2187 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Lever Lever is not locked Lever TERMINAL AND CONNECTOR REPAIR±HOW TO INSTALL AND REMOVE SPECIAL CONNECTORS B±48 58 Wire Harness Repair Manual (RM1022E) (2)Hold the connector to prevent it from slip

Page 2188 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Lever Lever is not locked Lever B±49 TERMINAL AND CONNECTOR REPAIR±HOW TO INSTALL AND REMOVE SPECIAL CONNECTORS 59 Wire Harness Repair Manual (RM1022E) 2. Connect the connector (1)Connect the conne

Page 2189 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Lever Lever is not locked TERMINAL AND CONNECTOR REPAIR±HOW TO INSTALL AND REMOVE SPECIAL CONNECTORS B±50 60 Wire Harness Repair Manual (RM1022E) (4)Cut the connection of the connector. NOTICE: Do n

Page 2190 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Coil spring Pin Convex partDouble locking device pin Primary locking device Lock Lock B±51 TERMINAL AND CONNECTOR REPAIR±HOW TO INSTALL AND REMOVE SPECIAL CONNECTORS 61 Wire Harness Repair Manual

Page 2191 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Connector A Connector B Connector A Lass than 1mmConnector B Bolt Cross±section of the bolt TERMINAL AND CONNECTOR REPAIR±HOW TO INSTALL AND REMOVE SPECIAL CONNECTORS B±52 62 Wire Harness Repair Ma

Page 2192 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Locking ArmHold back rib to pull connector back ribs B±53 TERMINAL AND CONNECTOR REPAIR±HOW TO INSTALL AND REMOVE SPECIAL CONNECTORS 63 Wire Harness Repair Manual (RM1022E) 1. Cut the connection o
