(d) Check the valve overall length.
Standard overall length:
Intake
98.29±98.79 mm (3.8697±3.8894 in.)
Exhaust
98.84±99.34 mm (3.8913±3.9110 in.)
Minimum overall length:
Intake
98.19 mm (3.8657 in.)
Exhaust
98.74 mm (3.8874 in.)
If the overall length is less than minimum, replace the valve.
(e) Check the surface of the valve stem tip for wear.
If the valve stem tip is worn, resurface the tip with a grinder
or replace the valve.
NOTICE: Do not grind off more than the minimum overall
length.
8. INSPECT AND CLEAN VALVE SEATS
(a) Using a 45° carbide cutter, resurface the valve seats.
Remove only enough metal to clean the seats.
(b) Check the valve seating position.
Apply a thin coat of prussian blue (or white lead) to the valve
face. Lightly press the valve against the seat. Do not rotate
the valve.
(c) Check the valve face and seat for the following:
wIf blue appears 360° around the face, the valve is
concentric. If not, replace the valve.
wIf blue appears 360° around the valve seat, the guide
and face are concentric. If not, resurface the seat.
wCheck that the seat contact is in the middle of the valve
face with the following width:
Intake
1.0±1.4 mm (0.039±0.055 in.)
Exhaust
1.2±1.6 mm (0.047±0.063 in.)
If not, correct the valve seats as follows:
wIf the seating is too high on the valve face, use 15° and
45° cutters to correct the seat.
± ENGINEENGINE MECHANICALEG±55
Page 1370 of 2543
wIf the seating is too low on the valve face, use 60° and
45° cutters to correct the seat.
(d) Hand±lap the valve and valve seat with an abrasive
compound.
(e) After hand±lapping, clean the valve and valve seat.
9. INSPECT VALVE SPRINGS
(a) Using a steel square, measure the deviation of the valve
spring.
Maximum deviation:
2.0 mm (0.079 in.)
If deviation is greater than maximum, replace the valve
spring.
(b) Using vernier calipers, measure the free length of the valve
spring.
Free length:
Blue painted mark
41.74 mm (1.6433 in.)
Yellow painted mark
41.70 mm (1.6417 in.)
If the free length is not as specified, replace the valve spring.
(c) Using a spring tester, measure the tension of the valve spring
at the specified installed length.
Installed tension:
186±206 N (19.0±21.0 kgf, 42±46 lbf) at 34.5 mm
(1.358 in.)
If the installed tension is not as specified, replace the valve
spring. EG±56
± ENGINEENGINE MECHANICAL
Page 1371 of 2543

10. INSPECT CAMSHAFTS AND BEARINGS
A. Inspect camshaft for runout
(a) Place the camshaft on V±blocks.
(b) Using a dial indicator, measure the circle runout at the center
journal.
Maximum circle runout:
0.08 mm ª(0.0031 in.)
If the circle runout is greater than maximum, replace the cam-
shaft.
B. Inspect cam lobes
Using a micrometer, measure the cam lobe height.
Standard cam lobe height:
Intake
44.570±44.670 mm (1.7547±1.7587 in.)
Exhaust
44.770±44.870 mm (1.7626±1.7665 in.)
Maximum cam lobe height:
Intake
44.42 mm (1.7488 in.)
Exhaust
44.62 mm (1.7567 in.)
If the cam lobe height is less than minimum, replace the cam-
shaft.
C. Inspect camshaft journals
Using a micrometer, measure the journal diameter.
Journal diameter:
28.949±28.965 mm (1.1397±1.1404 in.)
If the journal diameter is not as specified, check the oil clear-
ance.
D. Inspect camshaft bearings
Check the bearings for flaking and scoring.
If the bearings are damaged, replace the bearing caps and
cylinder head as a set.
E. Inspect camshaft journal oil clearance
(a) Clean the bearing caps and camshaft journals.
(b) Place the camshafts on the cylinder head.
(c) Lay a strip of Plastigage across each of the camshaft
journals.
± ENGINEENGINE MECHANICALEG±57
Page 1372 of 2543

(d) Install the bearing caps.
(See step 2 in cylinder head installation (2JZ±GE))
Torque: 20 NVm (200 kgfVcm, 14 ftVlbf)
NOTICE: Do not turn the camshaft.
(e) Remove the bearing caps.
(f) Measure the Plastigage at its widest point.
Standard oil clearance:
0.035±0.072 mm (0.0014±0.0028 in.)
Maximum oil clearance:
0.10 mm (0.0039 in.)
If the oil clearance is greater than maximum, replace the cam-
shaft. If necessary, replace the bearing caps and cylinder
head as a set.
(g) Completely remove the Plastigage.
F. Inspect camshaft thrust clearance
(a) Install the camshafts.
(See step 2 in cylinder head installation (2JZ±GE))
(b) Using a dial indicator, measure the thrust clearance while
moving the camshaft back and forth.
Standard thrust clearance:
0.080±0.190 mm (0.0031±0.0075 in.)
Maximum thrust clearance:
0.30 mm (0.0118 in.)
If the thrust clearance is greater than maximum, replace the
camshaft. If necessary, replace the bearing caps and cylin-
der head as a set.
11. INSPECT VALVE LIFTERS AND LIFTER BORES
(a) Using a caliper gauge, measure the lifter bore diameter of the
cylinder head.
Lifter bore diameter:
31.000±31.016 mm (1.2205±1.2211 in.)
(b) Using a micrometer, measure the lifter diameter.
Lifter diameter:
30.966±30.976 mm (1.2191±1.2195 in.)
(c) Subtract the lifter diameter measurement from the lifter bore
diameter measurement.
Standard oil clearance:
0.024±0.050 mm (0.0009±0.0020 in.)
Maximum oil clearance:
0.07 mm (0.0028 in.)
If the oil clearance is greater than maximum, replace the lifter.
If necessary, replace the cylinder head. EG±58
± ENGINEENGINE MECHANICAL
Page 1373 of 2543

12. INSPECT AIR INTAKE CHAMBER
Using a precision straight edge and feeler gauge, measure
the surfaces contacting the intake manifold for warpage.
Maximum warpage:
0.15 mm (0.0059 in.)
If warpage is greater than maximum, replace the chamber.
13. INSPECT INTAKE MANIFOLD
Using a precision straight edge and feeler gauge, measure
the surfaces contacting the cylinder head and air intake
chamber for warpage.
Maximum warpage:
0.15 mm (0.0059 in.)
If warpage is greater than maximum, replace the manifold.
14. 2JZ±GE:
INSPECT EXHAUST MANIFOLDS
Using a precision straight edge and feeler gauge, measure
the surfaces contacting the cylinder head for warpage.
Maximum warpage:
0.50 mm (0.0196 in.)
If warpage is greater than maximum, replace the manifold.
15. 2JZ±GTE:
INSPECT EXHAUST MANIFOLD
Using a precision straight edge and feeler gauge, measure
the surfaces contacting the cylinder head for warpage.
Maximum warpage:
0.80 mm (0.0315 in.)
If warpage is greater than maximum, replace the manifold.
± ENGINEENGINE MECHANICALEG±59
Page 1374 of 2543

16. INSPECT CYLINDER HEAD BOLTS
Using a vernier caliper, measure the thread outside diameter
of the bolt.
Standard outside diameter:
10.8±11.0 mm (0.425±0.433 in.)
Minimum outside diameter:
10.7 mm (0.421 in.)
If the diameter is less than minimum, replace the bolt.
CYLINDER HEAD ASSEMBLY
HINT:
wThoroughly clean all parts to be assembled.
wBefore installing the parts, apply new engine oil to all
sliding and rotating surfaces.
wReplace all gaskets and oil seals with new ones.
1. INSTALL HEATER UNION
HINT: When using a new cylinder head, a new heater union
must be installed.
(a) Apply adhesive to the end of the heater union as shown in the
illustration.
Adhesive:
Part No. 08833±00070, THREE BOND 1324 or equivalent
(b) Using a wooden block and hammer, tap in a new heater
union, leaving standard position protruding from the cylinder
head.
Standard protrusion:
2JZ±GE
48 mm (1.89 in.)
2JZ±GTE
73 mm (2.87 in.)
NOTICE: Do not tap it in too far.
2. INSTALL VALVES
(a) Install a new oil seal on the valve guide bushing. EG±60
± ENGINEENGINE MECHANICAL
Page 1375 of 2543
(b) Install these parts:
(1) Valve
(2) Spring seat
(3) Valve spring
(4) Spring retainer
HINT: Install the valve spring, facing the painted mark up-
ward.
(c) Using SST, compress the valve spring and place the 2
keepers around the valve stem.
SST 09202±70010
(d) Using a plastic±faced hammer, lightly tap the valve stem tip
to ensure a proper fit.
3. INSTALL VALVE LIFTERS AND SHIMS
(a) Install the valve lifter and shim.
(b) Check that the valve lifter rotates smoothly by hand.
4. INSTALL EGR COOLER
Install a new gasket and the EGR cooler with the 8 bolts.
Torque: 8.8 NVm (90 kgfVcm, 78 in.Vlbf)
5. 2JZ±GE:
INSTALL ECT SENSOR AND SENDER GAUGE
Torque: 20 NVm (200 kgfVcm, 14 ftVlbf)
6. 2JZ±GE:
INSTALL GROUND STRAP AND THROTTLE CABLE
BRACKET
7. 2JZ±GE:
INSTALL ENGINE HANGERS
Torque: 39 NVm (400 kgfVcm, 29 ftVlbf)
± ENGINEENGINE MECHANICALEG±61
Page 1376 of 2543

8. 2JZ±GTE:
INSTALL CAMSHAFT POSITION SENSORS
Install the gasket and sensor with the 2 bolts.
Torque: 8.8 NVm (90 kgfVcm, 78 in.Vlbf)
9. 2JZ±GTE:
INSTALL ENGINE HANGERS AND GROUND STRAP
Torque: 39 NVm (400 kgfVcm, 29 ftVlbf)
CYLINDER HEAD INSTALLATION
(2JZ±GE)
1. INSTALL CYLINDER HEAD
A. Place cylinder head on cylinder block
(a) Place a new cylinder head gasket in position on the cylinder
block.
NOTICE: Be sure to install it correctly.
(b) Place the cylinder head in position on the cylinder head
gasket.
B. Install cylinder head bolts
HINT:
wThe cylinder head bolts are tightened in 2 progressive
steps (steps (c) and (f)).
wIf any of bolts break or deform, replace them.
(a) Apply a light coat of engine oil on the threads and under the
heads of the cylinder head bolts.
(b) Install the 14 plate washers to each cylinder head bolt.
(c) Using a 10 mm bi±hexagon wrench, uniformly tighten the
cylinder head bolts, in several passes, in the sequence
shown.
Torque: 34 NVm (350 kgfVcm, 25 ftVlbf)
If any of the bolts do not meet the torque specification, re-
place the bolt.
(d) Mark the front of the cylinder head bolt head with paint. EG±62
