Page 697 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Replace fuse. Radio assembly faulty.Can cassette tape be installed in tape player? Check RAD No. 1 fuse is OK? Is +B applied to power amplifier?+B wire harness faulty. GND faulty. Is +B applied to rad

Page 698 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Tape PlayerCASSETTE TAPE CANNOT BE INSERTED Remove foreign object.Is there a foreign object inside tape player? Is auto search button of radio operating normally? Check if GND (wire harness side) to p

Page 699 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Functions OK if different cassette tape installed? Is there continuity in speaker wire harness? Temporarily install another speaker Functions OK? Radio assembly faulty. Replace fuse. Is radio operatin

Page 700 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Hissing sound from speaker? Is hiss produced by non±functioning speaker? Is there continuity in speaker wire harness? Temporarily install another speaker Functions OK? Power amplifier faulty. Rechec

Page 701 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Tape PlayerWOOFER SPEAKER DOES NOT WORK w/ Power Amplifier Check if RAD No. 2 fuse is OK?Replace fuse. Is radio operating normally?Radio receiver assembly faulty. Check if GND to power amplifier is OK

Page 702 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Function OK if different cassette tape installed? Operates normally after cleaning the heads? (See MAINTENANCE OF TAPE PLAYER) Cassette tape faulty? Tape PlayerSOUND QUALITY POOR (VOLUME FAINT) Tape P

Page 703 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Functions OK if different cassette tape installed?Radio assembly faulty. Is tape player operating normally?Cassette tape jammed. Is auto search button of radio operating normally?Radio assembly faulty

Page 704 of 2543

TOYOTA SUPRA 1995 Service Repair Manual Is CD already installed?Eject CD. Is auto search button of radio operating normally? CD CANNOT BE INSERTEDCD Player Is +B applied to CD player? Replace fuse. CD player faulty. Check if GND (wire harne
