Page 521 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-45 EXTERIOR/INTERIOR TRIM Rear Quarter Trim 19.Rear Quarter Trim A: REMOVAL 1) Remove the rear seat. <Ref. to SE-13, REMOV- AL, Rear Seat.> 2) Remove the side sill rear cover. 3) Remove the rear ra

Page 522 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-46 EXTERIOR/INTERIOR TRIM Sun Visor 20.Sun Visor A: REMOVAL Remove the mounting screws then detach sun vi- sor (A) and hook (B). B: INSTALLATION Install in the reverse order of removal. EI-00074 (A

Page 523 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-47 EXTERIOR/INTERIOR TRIM Roof Trim 21.Roof Trim A: REMOVAL CAUTION: When removing the clip, use great care not to damage the roof trim. 1) Disconnect the ground cable from battery. 2) Remove the

Page 524 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-48 EXTERIOR/INTERIOR TRIM Rear Gate Trim 22.Rear Gate Trim A: REMOVAL CAUTION: Be careful not to damage the clips or their holes. Remove the rear gate inner handle (A) from rear gate and then detac

Page 525 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-49 EXTERIOR/INTERIOR TRIM Floor Mat 23.Floor Mat A: REMOVAL 1) Remove the front seats. <Ref. to SE-6, REMOV- AL, Front Seat.> 2) Remove the rear seat cushion. <Ref. to SE-13, REMOVAL, Rear Seat.> 3

Page 526 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-50 EXTERIOR/INTERIOR TRIM Luggage Floor Mat 24.Luggage Floor Mat A: REMOVAL 1) Remove the back mat of rear seat backrest. 2) Remove the clips, then detach the rear floor mats and boxes. B: INSTALLA

Page 527 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-51 EXTERIOR/INTERIOR TRIM Instrument Panel Center Compartment 25.Instrument Panel Center Compartment A: REMOVAL 1) Disconnect the ground cable from battery. 2) Insert a flat tip screwdriver, and t

Page 528 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-52 EXTERIOR/INTERIOR TRIM Heat Shield Cover 26.Heat Shield Cover A: REMOVAL 1. FRONT HEAT SHIELD COVER Loosen the four bolts to remove front heat shield cover. 2. CENTER HEAT SHIELD COVER Loosen th
