SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-12
MECHANICAL
General Description
6. CRANKSHAFT AND PISTON
ME-00190
T1
T1
(9)(1)
(16)(17)(16)(17)(6)
(5)(4)(3)
(2) (12) (11) (10)
(7) (9) (9)
(8) (6) (5) (4)
(15)
(18)
(9)
(8) (10) (12)
(11)

Page 882 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-13
MECHANICAL
General Description
(1) Flywheel (MT model) (9) Snap ring (17) Crankshaft bearing #2, #4
(2) Reinforcement (AT model) (10) Connecting rod bolt (18) Crankshaft bearing #5
(3) Dri

Page 883 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-14
MECHANICAL
General Description
7. ENGINE MOUNTING
(1) Front cushion rubber (2) Front engine mounting bracketTightening torque: N⋅m (kgf-m, ft-lb)
T1: 35 (3.6, 25.8)
T2: 42 (4.3, 31.0)
T

Page 884 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-15
MECHANICAL
General Description
C: CAUTION
Wear working clothing, including a cap, protec-
tive goggles and protective shoes during operation.
Remove contamination including dirt and co

ME(H4SO)-15
MECHANICAL
General Description
C: CAUTION
Wear working clothing, including a cap, protec-
tive goggles and protective shoes during operation.
Remove contamination including dirt and corro-
sion before removal, installation or disassembly.
Keep the disassembled parts in order and pro-
tect them from dust or dirt.
Before removal, installation or disassembly, be
sure to clarify the failure. Avoid unnecessary re-
moval, installation, disassembly and replacement.
Be careful not to burn yourself, because each
part in the vehicle is hot after running.
Be sure to tighten bolts and nuts to the specified
torque.
Place shop jacks or rigid racks at the specified
points.
Before disconnecting electrical connectors of
sensors or units, be sure to disconnect the ground
cable from battery.
All parts should be thoroughly cleaned, paying
special attention to the engine oil passages, pis-
tons and bearings. Rotating parts and sliding parts such as piston,
bearing and gear should be coated with oil prior to
assembly.
Be careful not to let oil, grease or coolant contact
the timing belt, clutch disc and flywheel.
All removed parts, if to be reused, should be re-
installed in the original positions and directions.
Bolts, nuts and washers should be replaced with
new ones as required.
Even if necessary inspections have been made
in advance, proceed with assembly work while
making rechecks.
Remove or install engine in an area where chain
hoists, lifting devices, etc. are available for ready
use.
Be sure not to damage coated surfaces of body
panels with tools, or not to stain seats and windows
with coolant or oil. Place a cover over fenders, as
required, for protection.
Prior to starting work, prepare the following:
Service tools, clean cloth, containers to catch cool-
ant and oil, wire ropes, chain hoist, transmission
jacks, etc.
Lift-up or lower the vehicle when necessary.
Make sure to support the correct positions.
D: PREPARATION TOOL
1. SPECIAL TOOL
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
18231AA010 CAM SPROCKET
WRENCH Used for removing and installing cam
sprocket. (LH side)
Also the CAM SPROCKET WRENCH
(499207100) can be used.
24082AA230
(Newly adopted tool)CARTRIDGE Troubleshooting for electrical systems.
ST18231AA010
ST24082AA230

Page 885 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-16
MECHANICAL
General Description
22771AA030 SUBARU SELECT
MONITOR KITTroubleshooting for electrical systems.
English: 22771AA030 (Without printer)
German: 22771AA070 (Without printer)

Page 886 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-17
MECHANICAL
General Description
498457100 ENGINE STAND
ADAPTER LHUsed with ENGINE STAND (499817000).
498497100 CRANKSHAFT
STOPPERUsed for stopping rotation of flywheel when loos-
ening an

Page 887 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-18
MECHANICAL
General Description
18332AA010 OIL FILTER
WRENCHUsed for removing and installing oil filter.
(Outer diameter : 65 mm (2.56 in))
398744300
(2.0 L model)PISTON GUIDE Used for ins

Page 888 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-19
MECHANICAL
General Description
499017100 PISTON PIN GUIDE Used for installing piston pin, piston and con-
necting rod.
499037100 CONNECTING ROD
BUSHING
REMOVER &
INSTALLERUsed for remov
