SUBARU FORESTER 2004 Service Repair Manual AB-5 AIRBAG SYSTEM (DIAGNOSTIC) General Description  If any damage, opening, or rust is found on the airbag system wiring harness, do not attempt to re- pair using soldering equipment. Be sure to rep

Page 138 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-6 AIRBAG SYSTEM (DIAGNOSTIC) General Description  The removed front seat with the airbag module must be kept at least 200 mm (8 in) away from walls and other objects.  When painting or performing

Page 139 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-7 AIRBAG SYSTEM (DIAGNOSTIC) General Description  When storing a removed airbag module, do not place any objects on it or pile airbag modules on top of each other. If the airbag inflates for some

Page 140 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-8 AIRBAG SYSTEM (DIAGNOSTIC) General Description B: INSPECTION Before diagnosing, check the following items that might be related to the engine problem: 1. BATTERY Measure the battery voltage and s

Page 141 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-9 AIRBAG SYSTEM (DIAGNOSTIC) General Description  TEST HARNESS F ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FC010 TEST HARNESS F Used when measuring voltage, resistance of air- bag module h

Page 142 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-10 AIRBAG SYSTEM (DIAGNOSTIC) General Description  TEST HARNESS G ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FC020 TEST HARNESS G Used when measuring voltage, resistance of side airbag sen

Page 143 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-11 AIRBAG SYSTEM (DIAGNOSTIC) General Description  TEST HARNESS H ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FA030 TEST HARNESS H Used when measuring voltage, resistance of front sub-senso

Page 144 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-12 AIRBAG SYSTEM (DIAGNOSTIC) General Description  TEST HARNESS L ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FE000 TEST HARNESS L Used when measuring voltage, resistance of seat belt prete
