Page 2513 of 2870

SUBARU FORESTER 2004 Service Repair Manual 4AT(H4SO)-54
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
G: DTC 45 INTAKE MANIFOLD PRESSURE SIGNAL
DTC DETECTING CONDITION:
The input signal circuit of

Page 2514 of 2870

SUBARU FORESTER 2004 Service Repair Manual 4AT(H4SO)-55
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
5 CHECK INPUT SIGNAL FOR TCM.
1) Connect the connectors to TCM and ECM.
2) Start the engine, an

Page 2515 of 2870

SUBARU FORESTER 2004 Service Repair Manual 4AT(H4SO)-56
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
H: DTC 71 SHIFT SOLENOID 1
DTC DETECTING CONDITION:
The output signal circuit of shift solenoid

Page 2516 of 2870

SUBARU FORESTER 2004 Service Repair Manual 4AT(H4SO)-57
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
2 CHECK HARNESS CONNECTOR BETWEEN
TCM AND TRANSMISSION.
Measure the resistance of harness betw

4AT(H4SO)-57
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
2 CHECK HARNESS CONNECTOR BETWEEN
TCM AND TRANSMISSION.
Measure the resistance of harness between
TCM connector and chassis ground.
Connector & terminal
(B54) No. 22 — Chassis ground:Is the resistance more than 1
MΩ?Go to step 3.Repair the short
circuit in harness
between TCM and
transmission con-
nector.
3 CHECK SHIFT SOLENOID 1.
Measure the resistance between transmission
connector terminals.
Connector & terminal
(T4) No. 1 — No. 16:Is the resistance 10 — 16 Ω? Go to step 4.Go to step 7.
4 CHECK OUTPUT SIGNAL EMITTED FROM
TCM.
1) Connect the connectors to TCM and trans-
mission.
2) Turn the ignition switch to ON (engine
OFF).
3) Move the select lever to “D” range.
4) Measure the voltage between TCM con-
nector and chassis ground.
Connector & terminal
(B54) No. 22 (+) — Chassis ground (
−):Is the voltage more than 9 V? Go to step 5.Go to step 6.
5 CHECK OUTPUT SIGNAL EMITTED FROM
TCM.
1) Turn the HOLD mode switch to ON.
2) Measure the voltage between TCM con-
nector and chassis ground.
Connector & terminal
(B54) No. 22 (+) — Chassis ground (
−):Is the voltage less than 1 V? Even if the
POWER indicator
light was blinking,
the circuit has
returned to a nor-
mal condition at
this time. A tempo-
rary poor contact
of the connector or
harness may be
the cause. Repair
the harness or
contact in TCM.Go to step 6.
6 CHECK POOR CONTACT.Is there poor contact in shift
solenoid 1 circuit?Repair poor con-
tact.Replace the TCM.
Transmission Con-
trol Module
(TCM).>
7 CHECK SHIFT SOLENOID 1 (IN TRANSMIS-
SION).
1) Remove the transmission connector from
bracket.
2) Lift-up or raise the vehicle and support with
rigid rack.
NOTE:
Raise all wheels off ground.
3) Drain the ATF.
CAUTION:
Do not drain the ATF until it cools down.
4) Remove the oil pan, and disconnect con-
nector from shift solenoid 1.
5) Measure the resistance between shift sole-
noid 1 connector and transmission ground.
Te r m i n a l s
No. 1 — Transmission ground:Is the resistance 10 — 16 Ω? Go to step 8.Replace the shift
solenoid 1. to 4AT-71, Shift
Solenoids, Duty
Solenoids and ATF
Temperature Sen-
sor.> Step Check Yes No

Page 2517 of 2870

SUBARU FORESTER 2004 Service Repair Manual 4AT(H4SO)-58
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
8 CHECK HARNESS CONNECTOR BETWEEN
SHIFT SOLENOID 1 AND TRANSMISSION.
Measure the resistance of

Page 2518 of 2870

SUBARU FORESTER 2004 Service Repair Manual 4AT(H4SO)-59
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
I: DTC 72 SHIFT SOLENOID 2
DTC DETECTING CONDITION:
The output signal circuit of shift solenoid

Page 2519 of 2870

SUBARU FORESTER 2004 Service Repair Manual 4AT(H4SO)-60
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
Step Check Yes No
1 CHECK HARNESS CONNECTOR BETWEEN
TCM AND TRANSMISSION.
1) Turn the ignition

4AT(H4SO)-60
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
Step Check Yes No
1 CHECK HARNESS CONNECTOR BETWEEN
TCM AND TRANSMISSION.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from TCM and
transmission.
3) Measure the resistance of harness
between TCM and shift solenoid 2 connector.
Connector & terminal
(B54) No. 5 — (B11) No. 2:Is the resistance less than 1
Ω?Go to step 2.Repair the open
circuit in harness
between TCM and
transmission con-
nector.
2 CHECK HARNESS CONNECTOR BETWEEN
TCM AND TRANSMISSION.
Measure the resistance of harness between
TCM connector and transmission ground.
Connector & terminal
(B54) No. 5 — Chassis ground:Is the resistance more than 1
MΩ?Go to step 3.Repair the short
circuit in harness
between TCM and
transmission con-
nector.
3 CHECK SHIFT SOLENOID 2.
Measure the resistance between transmission
connector terminals.
Connector & terminal
(T4) No. 2 — No. 16:Is the resistance 10 — 16 Ω? Go to step 4.Go to step 6.
4 CHECK OUTPUT SIGNAL EMITTED FROM
TCM.
1) Connect the connectors to TCM and trans-
mission.
2) Lift-up or raise the vehicle and support with
rigid rack.
N
OTE:
Raise all wheels off ground.
3) Start the engine and warm-up the transmis-
sion until ATF temperature is above 80°C
(176°F).
NOTE:
If ambient temperature is below 0°C (32°F),
drive the vehicle until ATF reaches its operating
temperature.
4) Move the selector lever to “D” range, and
slowly increase vehicle speed to 50 km/h (31
MPH).
NOTE:
The speed difference between front and rear
wheels may light the ABS warning light, but this
indicates no malfunction. When AT control diag-
nosis is finished, perform the ABS memory
clearance procedure of on-board diagnostics
system. Mode.>
5) Measure the voltage between TCM con-
nector and chassis ground.
Connector & terminal
(B54) No. 5 (+) — Chassis ground (
−):Is the voltage less than 1 V? Even if the
POWER indicator
light was blinking,
the circuit has
returned to a nor-
mal condition at
this time. A tempo-
rary poor contact
of the connector or
harness may be
the cause. Repair
the harness or
connector in TCM
and transmission.Go to step 5.
5 CHECK POOR CONTACT.Is there poor contact in shift
solenoid 2 circuit?Repair the poor
contact.Replace the TCM.
Transmission Con-
trol Module
(TCM).>

Page 2520 of 2870

SUBARU FORESTER 2004 Service Repair Manual 4AT(H4SO)-61
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
6 CHECK SHIFT SOLENOID 2 (IN TRANSMIS-
SION).
1) Remove the transmission connector from
bracke
