SUBARU FORESTER 2004 Service Repair Manual SUNROOF/T-TOP/CONVERTIBLE TOP
(SUNROOF)
SR
Page
1. General Description ....................................................................................2
2. Sunroof Control System ................

Page 466 of 2870

SUBARU FORESTER 2004 Service Repair Manual SR-2
SUNROOF/T-TOP/CONVERTIBLE TOP (SUNROOF)
General Description
1. General Description
A: COMPONENT
(1) Sunroof lid (7) Harness (13) Shim
(2) Rear drain ASSY (8) Sunshade
(3) Frame ASSY (9) GarnishTi

Page 467 of 2870

SUBARU FORESTER 2004 Service Repair Manual SR-3
SUNROOF/T-TOP/CONVERTIBLE TOP (SUNROOF)
General Description
B: CAUTION
Before disassembling or reassembling parts, always
disconnect battery ground cable. When replacing ra-
dio, control module

Page 468 of 2870

SUBARU FORESTER 2004 Service Repair Manual SR-4
SUNROOF/T-TOP/CONVERTIBLE TOP (SUNROOF)
Sunroof Control System
2. Sunroof Control System
A: WIRING DIAGRAM
1. SUNROOF
<Ref. to WI-263, WIRING DIAGRAM, Sunroof System.>
B: INSPECTION
Symptom Check

Page 469 of 2870

SUBARU FORESTER 2004 Service Repair Manual SR-5
SUNROOF/T-TOP/CONVERTIBLE TOP (SUNROOF)
Sunroof Lid
3. Sunroof Lid
A: REMOVAL
1) Completely close sunroof lid and open sunshade.
2) Detach the four covers (A) and then remove eight
nuts.
3) Caref

Page 470 of 2870

SUBARU FORESTER 2004 Service Repair Manual SR-6
SUNROOF/T-TOP/CONVERTIBLE TOP (SUNROOF)
Sunroof Assembly
4. Sunroof Assembly
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove roof trim. <Ref. to EI-47, REMOVAL,
Roof Trim.>
3) R

Page 471 of 2870

SUBARU FORESTER 2004 Service Repair Manual SR-7
SUNROOF/T-TOP/CONVERTIBLE TOP (SUNROOF)
Sunroof Assembly
E: INSPECTION
1. CHECK FOR MOVEMENT OF SUN-
SHADE
1) Attach a spring scale to sunshade edge using a
cloth.
2) Pull the spring scale to mea

Page 472 of 2870

SUBARU FORESTER 2004 Service Repair Manual SR-8
SUNROOF/T-TOP/CONVERTIBLE TOP (SUNROOF)
Sunroof Motor
5. Sunroof Motor
A: REMOVAL
CAUTION:
Fully close sunroof when removing sunroof mo-
tor.
When removing clip, use great care to not dam-
ag

SR-8
SUNROOF/T-TOP/CONVERTIBLE TOP (SUNROOF)
Sunroof Motor
5. Sunroof Motor
A: REMOVAL
CAUTION:
Fully close sunroof when removing sunroof mo-
tor.
When removing clip, use great care to not dam-
age the roof trim.
1) Completely close the sunroof.
2) Disconnect the ground cable from battery.
3) Remove roof trim. Roof Trim.>
4) Disconnect harness connector (A) and remove
sunroof motor mounting screw (B) and nut (C).
B: INSTALLATION
CAUTION:
Be careful not to move the sunroof cable when
installing sunroof motor.
1) Install sunroof motor.
2) Connect sunroof motor harness connector and
then connect battery ground cable.
3) Reset the sunroof motor. JUSTMENT, Sunroof Motor.>
4) Check sunroof operation with the following pro-
cedure.
5) Install the roof trim. TION, Roof Trim.>
C: ADJUSTMENT
1) Reset the sunroof motor.
(1) Close the sunroof lid completely, and then
push the switch to close for more than 1 second.
(At this time, the sunroof operates 50 mm (1.97
in) each intermittently. And also the switch is
needed to push for several times.)
(2) Open the sunroof lid approx. 400 mm (15.75
in).
(3) Close the sunroof lid completely, and then
push the switch to close for more than 1 second.
(Sunroof operates automatically by performing
this operation.)
D: INSPECTION
1. AUTO REVERSE FUNCTION
1) Open the sunroof lid.
2) While the sunroof lid closing automatically, press
the switch to open and check if auto reverse func-
tion operates properly.
3) Check that the sunroof opens 150 mm (5.91 in)
by auto reverse function operated.
CAUTION:
Do not check the auto reverse operation with
pinching any object.
NOTE:
Auto function is canceled if auto reverse function
operates more than five times.
Reset if auto function is canceled. ADJUSTMENT, Sunroof Motor.>
Checking order Switch position
(1) Completely close sunroof. Closed
(2) Open sunroof 500 mm (19.7 in) away
from completely closed position.Open
(3) Completely open sunroof. Open
(4) Close sunroof 200 mm (7.87 in) from
completely closed position.Closed
(5) Completely close sunroof. Closed
SR-00016
(A)
(C)
(B)
(C)
