Page 1017 of 2870

SUBARU FORESTER 2004 Service Repair Manual CO(H4SO)-34
COOLING
Radiator Cap
7. Radiator Cap
A: INSPECTION
1) Attach the radiator cap to tester.
2) Increase the pressure until tester gauge pointer
stops. Radiator cap is functioning properly if

Page 1018 of 2870

SUBARU FORESTER 2004 Service Repair Manual CO(H4SO)-35
COOLING
Radiator Main Fan and Fan Motor
8. Radiator Main Fan and Fan
Motor
A: REMOVAL
1. NON-TURBO MODEL
1) Set the vehicle on a lift.
2) Disconnect the ground cable from battery.
3) Lift

Page 1019 of 2870

SUBARU FORESTER 2004 Service Repair Manual CO(H4SO)-36
COOLING
Radiator Main Fan and Fan Motor
2. TURBO MODEL
1) Set the vehicle on a lift.
2) Disconnect the ground cable from battery.
3) Remove the radiator upper bracket. (AT model)
4) Lift-u

Page 1020 of 2870

SUBARU FORESTER 2004 Service Repair Manual CO(H4SO)-37
COOLING
Radiator Main Fan and Fan Motor
15) Disconnect the radiator inlet hose.
16) Disconnect the power steering hose from radi-
ator clip.
17) Remove the radiator main fan motor assembly

Page 1021 of 2870

SUBARU FORESTER 2004 Service Repair Manual CO(H4SO)-38
COOLING
Radiator Main Fan and Fan Motor
9) Connect the main fan motor (A) and sub fan mo-
tor (B).
10) Install the under cover.
11) Lower the vehicle.
12) Connect the battery ground cable

Page 1022 of 2870

SUBARU FORESTER 2004 Service Repair Manual CO(H4SO)-39
COOLING
Radiator Main Fan and Fan Motor
10) Install the radiator main fan motor assembly
mounting bolts.
Tightening torque:
4.9 N
⋅m (0.5 kgf-m, 3.6 ft-lb)
11) Install the reservoir tank

Page 1023 of 2870

SUBARU FORESTER 2004 Service Repair Manual CO(H4SO)-40
COOLING
Radiator Sub Fan and Fan Motor
9. Radiator Sub Fan and Fan
Motor
A: REMOVAL
Refer to Radiator Main Fan and Fan Motor. <Ref. to
CO(H4SO)-35, REMOVAL, Radiator Main Fan and
Fan Moto

Page 1024 of 2870

SUBARU FORESTER 2004 Service Repair Manual CO(H4SO)-41
COOLING
Reservoir Tank
10.Reservoir Tank
A: REMOVAL
1) Disconnect the over flow hose from radiator filler
neck position.
2) Remove the bolts which install reservoir tank
onto radiator main
