Page 553 of 2870

SUBARU FORESTER 2004 Service Repair Manual CRUISE CONTROL SYSTEM CC Page 1. General Description ....................................................................................2 2. Actuator .................................................

Page 554 of 2870

SUBARU FORESTER 2004 Service Repair Manual CC-2 CRUISE CONTROL SYSTEM General Description 1. General Description A: COMPONENT 1. EXCEPT 2.5 L TURBO MODEL NOTE: Electrical component location are for LHD vehicles. Cruise control actuator and cru

Page 555 of 2870

SUBARU FORESTER 2004 Service Repair Manual CC-3 CRUISE CONTROL SYSTEM General Description 2. 2.5 L TURBO MODEL (1) (2) (3) (4) (6)(7) CC-00262 (5) (1) Inhibitor switch (AT model) (4) Clutch switch (MT model) (7) Neutral position switch (MT mo

Page 556 of 2870

SUBARU FORESTER 2004 Service Repair Manual CC-4 CRUISE CONTROL SYSTEM General Description B: CAUTION  Before disassembling or reassembling parts, al- ways disconnect the battery ground cable. When re- pairing the radio, control module and oth

Page 557 of 2870

SUBARU FORESTER 2004 Service Repair Manual CC-5 CRUISE CONTROL SYSTEM Actuator 2. Actuator A: REMOVAL CAUTION:  Be careful not to apply excessive load to the wire cable when adjusting and/or installing; oth- erwise, the actuator may be deform

Page 558 of 2870

SUBARU FORESTER 2004 Service Repair Manual CC-6 CRUISE CONTROL SYSTEM Actuator C: INSPECTION Measure the cruise control actuator resistance. If NG, replace the cruise control actuator. Terminal No. Standard 4 and 1 Approx. 5 Ω 4 and 2 Approx

Page 559 of 2870

SUBARU FORESTER 2004 Service Repair Manual CC-7 CRUISE CONTROL SYSTEM Cruise Control Module 3. Cruise Control Module A: NOTE Engine Control Module (ECM) controls cruise con- trol system (Turbo model). B: REMOVAL 1. NON-TURBO MODEL 1) Disconnec

Page 560 of 2870

SUBARU FORESTER 2004 Service Repair Manual CC-8 CRUISE CONTROL SYSTEM Cruise Control Main Switch 4. Cruise Control Main Switch A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the screws and clip from instrument panel lower co
