Page 105 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-5
AIRBAG SYSTEM
General Description
When painting or performing sheet metal work
on the side of the vehicle, including the side sill,
center pillar, and front and rear doors, remove the
side airb

Page 106 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-6
AIRBAG SYSTEM
General Description
When storing a removed airbag module, do not place any objects on it or pile airbag modules on top of
each other. If the airbag inflates for some reason when i

Page 107 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-7
AIRBAG SYSTEM
General Description
C: PREPARATION TOOL
1. SPECIAL TOOL
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
98299FC030 DEPLOYMENT
ADAPTER A Used for deploying the side airbag module.
U

Page 108 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-8
AIRBAG SYSTEM
General Description
2. GENERAL TOOL
98299PA030 DEPLOYMENT
TOOL Used for deploying the airbag module.
Used with DEPLOYMENT ADAPTER A
(98299FC030).
TOOL NAME REMARKS
TO RX
® T30

Page 109 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-9
AIRBAG SYSTEM
Airbag Connector
2. Airbag Connector
A: OPERATION
1. POWER SUPPLY
1) How to disconnect:
(1) Move the slide lock (A) in the direction of ar-
row.
(2) Pull the female connector in the

Page 110 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-10
AIRBAG SYSTEM
Airbag Connector
3. DRIVER’S AIRBAG MODULE AND PRE-
TENSIONER
1) How to disconnect:
(1) Using a flat tip screwdriver, pry the push
lock upward to unlock.
(2) Pull the connector t

Page 111 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-11
AIRBAG SYSTEM
Airbag Connector
(2) With the slide lock pushed, pull the connec-
tor in the direction of arrow and disconnect it.
CAUTION:
When pulling, be sure to hold onto the connec-
tor and n

Page 112 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-12
AIRBAG SYSTEM
Inspection Locations After a Collision
3. Inspection Locations After a
Collision
A: REPLACEMENT
When airbag system is deployed, replace the fol-
lowing parts.
1. FRONT COLLISION
1

AB-12
AIRBAG SYSTEM
Inspection Locations After a Collision
3. Inspection Locations After a
Collision
A: REPLACEMENT
When airbag system is deployed, replace the fol-
lowing parts.
1. FRONT COLLISION
1) Driver’s airbag module
2) Passenger’s airbag module
3) Driver’s seat belt (pretensioner, lap seat belt pre-
tensioner)
4) Passenger’s seat belt (pretensioner)
5) Airbag control module
6) Front sub-sensor
7) Roll connector
2. SIDE COLLISION
1) Airbag control module
2) Side airbag module (operating side seat bag)
3) Side airbag sensor (operating side)
3. INSPECTION OF OTHER PARTS
Check for the following parts, replace the damaged
parts with new ones.
1) Steering wheel and steering shaft
Check the steering wheel and steering shaft for
mounting condition and deflection of axial and radi-
al direction. Check the steering shaft for deflection
of axial direction with tilt lever released. (After a col-
lision, absorbing part of steering shaft may inflate.)
2) Check the direct type connector of driver’s air-
bag module, pretensioner, etc. for damage, and
also check each harness for pinch and connector
damage. If damage is found, replace the harness
as a unit.
B: INSPECTION
If the vehicle is involved in a collision on any side,
even if it is a slight collision, be sure to check the
following system parts.
1. DRIVER’S AIRBAG MODULE
1) Check for the following, and replace damaged
parts with new ones.
Airbag module is cracked or deformed.
Harness and/or connector is cracked, deformed
or open. Lead wire is exposed.
The module surface is fouled with grease, oil,
water or cleaning solvent.
2) When installing a new driver’s airbag module,
check the following. If necessary, install a new air-
bag module and steering wheel.
The steering wheel is in the way, making it diffi-
cult to install the airbag module. The clearance between the driver’s airbag mod-
ule and steering wheel is not constant.
The steering wheel deformation in axial and radi-
al directions exceed limits.
Specifications:
Height deflection A
Less than 6 mm (0.24 in)
O.D. deflection L
Less than 17 mm (0.67 in)
2. PASSENGER’S AIRBAG MODULE
Check for the following, and replace damaged
parts with new ones.
Airbag module is cracked or deformed.
Harness and/or connector is cracked, deformed
or open. Lead wire is exposed.
Mounting bracket is cracked or deformed.
3. SIDE AIRBAG MODULE
Check for the following, and replace damaged
parts with new ones.
Front seat is damaged or deformed.
Harness and/or connector is cracked, deformed
or open.
Lead wire is exposed.
4. AIRBAG CONTROL MODULE
Check for the following, and replace damaged
parts with new ones.
Control module is cracked or deformed.
Mounting bracket is cracked or deformed.
Connector is scratched or deformed.
Airbag is deployed.
Side airbag is deployed.
AB-00028
L
A
