SUBARU FORESTER 2004 Service Repair Manual AB-21
AIRBAG SYSTEM
Front Sub Sensor
10.Front Sub Sensor
A: REMOVAL
1) Turn the ignition switch to OFF.
2) Disconnect the ground cable from battery, and
wait for at least 20 seconds before starting wo

Page 122 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-22
AIRBAG SYSTEM
Airbag Module Disposal (Deployment Processing On Vehicle)
11.Airbag Module Disposal (De-
ployment Processing On Ve-
hicle)
A: OPERATION
CAUTION:
Do not discard an undeployed air

AB-22
AIRBAG SYSTEM
Airbag Module Disposal (Deployment Processing On Vehicle)
11.Airbag Module Disposal (De-
ployment Processing On Ve-
hicle)
A: OPERATION
CAUTION:
Do not discard an undeployed airbag mod-
ules because it may cause a serious personal
injury when accidentally deployed.
As a rule, the airbag module should be de-
ployed while still installed in the vehicle. Do not
remove the airbag modules unless necessary.
Deployment of the airbag module should be
done on a flat place free from any possible dan-
ger. Avoid deploying outdoors during rainy or
windy weather.
Deploying the airbag module causes a high
explosive noise, be sure to warn people in the
area, and do not allow anyone within a 5 m (16
ft) radius of the disposal site.
Some smoke will be emitted from deployment
of the airbag module. Therefore, it must be de-
ployed in a well-ventilated place with no smoke
detector nearby.
Wear protective gloves, safety goggles and
earplugs during this operation. Wash your hands
afterwards.
After deployment, the airbag module will be
especially hot, leave it unattended for 40 min-
utes, and then discard it.
Do not let water get on the deployed airbag
module.
Wrap the deployed airbag module in an air-
tight vinyl bag, and discard it.
If circumstances do not permit the airbag
module deployment, contact the SUBARU deal-
er.
1. DRIVER’S AIRBAG MODULE
1) Turn the ignition switch to OFF.
2) Disconnect the ground cable from battery and
wait for at least 20 seconds before starting work.
3) Remove the lower cover. MOVAL, Instrument Panel Assembly.>4) Disconnect the airbag connector (AB30) and
(AB2) below steering column.
5) Short the terminal to alligator clip furnished as
deployment tool (A).
6) Connect the deployment tool and deployment
adapter A (B).
CAUTION:
The deployment tool should be kept shorted
terminals until just before deployment of airbag
module.
7) Connect the deployment adapter A to airbag
connector (AB30).
(A) Deployment tool:
(Tool number 98299PA030)
(B) Deployment adapter A:
(Tool number 98299SA030)
(1) Deployment adapter A:
(Tool number 98299SA030)
AB-00197
AB30
AB2
SB-00016
AB-00198
AB30
(1)

Page 123 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-23
AIRBAG SYSTEM
Airbag Module Disposal (Deployment Processing On Vehicle)
8) Extend the wiring of deployment tool to the limit,
and make sure that the vehicle is empty. Close all
the windows, sunr

Page 124 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-24
AIRBAG SYSTEM
Airbag Module Disposal (Deployment Processing On Vehicle)
8) Extend the wiring of deployment tool to the limit,
and make sure that the vehicle is empty. Close all
the windows, sunr

Page 125 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-25
AIRBAG SYSTEM
Airbag Module Disposal (Deployment Processing On Vehicle)
8) Extend the wiring of deployment tool to the limit,
and make sure that the vehicle is empty. Close all
the windows, sunr

Page 126 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-26
AIRBAG SYSTEM
Disposal of Airbag Module (Deploying After Removal from Vehicle)
12.Disposal of Airbag Module
(Deploying After Removal
from Vehicle)
A: OPERATION
CAUTION:
Do not discard an un

AB-26
AIRBAG SYSTEM
Disposal of Airbag Module (Deploying After Removal from Vehicle)
12.Disposal of Airbag Module
(Deploying After Removal
from Vehicle)
A: OPERATION
CAUTION:
Do not discard an undeployed airbag module
because it may cause serious personal injury
when accidentally deployed.
As a rule, the airbag module should be de-
ployed while still installed in the vehicle. Do not
remove the airbag modules unless necessary.
Deployment of the airbag module should be
done on a flat place free from any possible dan-
ger. Avoid deploying outdoors during rainy or
windy weather.
Do not damage the airbag module or drop it.
Deploying the airbag module causes a high
explosive noise, be sure to warn people in the
area, and do not allow anyone within a 5 m (16
ft) radius of the disposal site.
Some smoke will be emitted from deployment
of the airbag module. Therefore, it must be de-
ployed in a well ventilated place with no smoke
detector nearby.
Wear protective gloves, safety goggles and
earplugs during this operation. Wash your
hands afterwards.
After deployment, the airbag module will be
especially hot, leave it unattended for 40 min-
utes, and then discard it.
Do not let water get on the deployed airbag
module.
Wrap the deployed airbag module in an air-
tight vinyl bag, and discard it.
If circumstances do not permit the airbag
module deployment, contact the SUBARU deal-
er.
1. DRIVER’S AIRBAG MODULE
1) Turn the ignition switch to OFF.
2) Disconnect the ground cable from battery and
wait for at least 20 seconds before starting work.
3) Remove the driver’s airbag module. 14, Driver’s Airbag Module.>4) Install the removed bolts to airbag module.
5) Bundle three automotive wire harnesses [each
with a sectional area of 1.25 mm
2 (0.00194 sq in) or
more], and bind them twofold around airbag mod-
ule stay.
6) Short the terminal to alligator clip furnished as
deployment tool (A).
7) Connect the deployment tool and deployment
adapter D (B).
CAUTION:
The deployment tool should be kept shorted
terminals until just before deployment of airbag
module.
8) Connect the deployment adapter D connector to
airbag module.
(A) Deployment tool:
(Tool number 98299PA030)
(B) Deployment adapter D:
(Tool number 98299SA010)
AB-00780
AB-00048
SB-00021
(A)
(B)

Page 127 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-27
AIRBAG SYSTEM
Disposal of Airbag Module (Deploying After Removal from Vehicle)
9) Install the airbag module with pad side facing up-
ward on a wheel with tire.
10) Put three tires without wheels

Page 128 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-28
AIRBAG SYSTEM
Disposal of Airbag Module (Deploying After Removal from Vehicle)
5) Short the terminal to alligator clip furnished as
deployment tool (A)
6) Connect the deployment tool and deploym
