SUBARU FORESTER 2004 Service Repair Manual EI-37 EXTERIOR/INTERIOR TRIM Glove Box 13.Glove Box A: REMOVAL 1) Open the glove box. 2) Loosen the screws to remove glove box. B: INSTALLATION Install in the reverse order of removal. (A) Hook (B) Cl

Page 514 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-38 EXTERIOR/INTERIOR TRIM Roof Rail 14.Roof Rail A: REMOVAL 1) Remove the roof trim. <Ref. to EI-47, REMOVAL, Roof Trim.> 2) Remove the five mounting nuts. 3) Detach the clip at front edge sideway

Page 515 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-39 EXTERIOR/INTERIOR TRIM Console Box 15.Console Box A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the console front cover. 3) Remove the shift knob (MT model). 4) Loosen the sc

Page 516 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-40 EXTERIOR/INTERIOR TRIM Instrument Panel Assembly 16.Instrument Panel Assembly A: REMOVAL CAUTION:  All airbag system wiring harness and connec- tors are colored yellow. Do not use electrical te

Page 517 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-41 EXTERIOR/INTERIOR TRIM Instrument Panel Assembly 9) Loosen the screws and clips, and then remove the side console panel. 10) Remove the passenger’s airbag module. <Ref. to AB-15, REMOVAL, Pass

Page 518 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-42 EXTERIOR/INTERIOR TRIM Instrument Panel Assembly 6) Loosen the four instrument panel installation bolts. 7) Remove the driver’s and passenger’s airbag mod- ule. <Ref. to AB-14, REMOVAL, Driv

Page 519 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-43 EXTERIOR/INTERIOR TRIM Upper Inner Trim 17.Upper Inner Trim A: REMOVAL 1) Remove the lower inner trim. <Ref. to EI-44, RE- MOVAL, Lower Inner Trim.> 2) Remove the front molding (A). 3) Remove th

Page 520 of 2870

SUBARU FORESTER 2004 Service Repair Manual EI-44 EXTERIOR/INTERIOR TRIM Lower Inner Trim 18.Lower Inner Trim A: REMOVAL 1) Remove the side sill front cover (A). 2) Remove the rear seat cushion <Ref. to SE-13, REMOVAL, Rear Seat.>, then remove
