Page 705 of 2870

SUBARU FORESTER 2004 Service Repair Manual NT-4 NOTE Note  Lift  Rigid rack NT-00003 NT-00004

Page 706 of 2870

SUBARU FORESTER 2004 Service Repair Manual NT-5 NOTE Note  Jack-up point (A) Front (B) Rear NT-00005 (A) (B)

Page 707 of 2870

SUBARU FORESTER 2004 Service Repair Manual NT-6 NOTE Note 8. TIE-DOWNS Tie-downs are used when transporting vehicles and when using the chassis dynamo. Attach tie-downs only to the specified points on the vehicle. (A) Front (C) Hook for tie-d

Page 708 of 2870

SUBARU FORESTER 2004 Service Repair Manual NT-7 NOTE Note  Chain direction at tie-down condition  Chain pulling range at tie-down condition Vehicle sinking volume at tie-down condition Measure the distance L between tire highest point to ar

Page 709 of 2870

SUBARU FORESTER 2004 Service Repair Manual NT-8 NOTE Note 10.FRONT HOOD STAY INSTALLATION  At the check and general maintenance  When wider hood opening is necessary Set stay into the hole of hood inner as shown in the figure below. NOTE: Be

Page 710 of 2870

SUBARU FORESTER 2004 Service Repair Manual IDENTIFICATION ID Page 1. Identification ................................................................................................2

Page 711 of 2870

SUBARU FORESTER 2004 Service Repair Manual ID-2 IDENTIFICATION Identification 1. Identification A: IDENTIFICATION 1. IDENTIFICATION NUMBER AND LABEL LOCATIONS The VIN (Vehicle Identification Numbers) is used to classify the vehicle. Positionin

Page 712 of 2870

SUBARU FORESTER 2004 Service Repair Manual ID-3 IDENTIFICATION Identification ID-00016 VA-type T-typeLabel location Stamp location ID-00017 41JF1 SG 5L SG 5 A L 1KK 43 EJ 201NWUAA T Y755 XF 3A A G 00200 EC1 0 23 0 applied modeloption code trim
