SUBARU FORESTER 2004 Service Repair Manual LI-27 LIGHTING SYSTEM High-mounted Stop Light 23.High-mounted Stop Light A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the cap (a) by prying on the edge with screwdriver. 3) Remove

Page 282 of 2870

SUBARU FORESTER 2004 Service Repair Manual LI-28 LIGHTING SYSTEM Side Turn Signal Light 24.Side Turn Signal Light A: REMOVAL 1) Disconnect the ground cable from battery. 2) Pull out the light from body while pushing it in di- rection of vehicl

Page 283 of 2870

SUBARU FORESTER 2004 Service Repair Manual LI-29 LIGHTING SYSTEM Spot Map Light 25.Spot Map Light A: REMOVAL 1) Disconnect the ground cable from battery. 2) Insert a flat tip screwdriver to the slot of lens, and then pry the lens to remove. 3)

Page 284 of 2870

SUBARU FORESTER 2004 Service Repair Manual LI-30 LIGHTING SYSTEM Room Light 26.Room Light A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the lens (A) and room light mounting screws (B). 3) Disconnect the harness connectors a

Page 285 of 2870

SUBARU FORESTER 2004 Service Repair Manual LI-31 LIGHTING SYSTEM Luggage Room Light 27.Luggage Room Light A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the lens (A) and luggage room light mounting screws (B). 3) Disconnect

Page 286 of 2870

SUBARU FORESTER 2004 Service Repair Manual LI-32 LIGHTING SYSTEM Glove Box Light 28.Glove Box Light A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the glove box. <Ref. to EI-37, REMOV- AL, Glove Box.> 3) Disconnect the harne

Page 287 of 2870

SUBARU FORESTER 2004 Service Repair Manual FUJI HEAVY INDUSTRIES LTD. G8080GE7 2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX BODY SECTION This service manual has been prepared to provide SUBARU service personnel with the necessary informa

Page 288 of 2870

SUBARU FORESTER 2004 Service Repair Manual 2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX BODY SECTION G8080GE7 CRUISE CONTROL SYSTEM CC CRUISE CONTROL SYSTEM (DIAGNOSTIC)CC(H4SO) CRUISE CONTROL SYSTEM (DIAGNOSTIC)CC(H4DOTC) CRUISE CONTROL
