GW-7
GLASS/WINDOW/MIRROR
Power Window Control Switch
3. Power Window Control
Switch
A: REMOVAL
1. MAIN SWITCH
1) Disconnect the ground cable from battery.
2) Using a flat tip screwdriver, remove the screw cov-
er.
3) Loosen the screw to remove the power window
main switch.
4) Disconnect the connector.
2. SUB-SWITCH
1) Disconnect the ground cable from battery.
2) Remove the screw which secures switch panel.3) Remove the switch panel.
4) Disconnect the connector.
B: INSTALLATION
1. MAIN SWITCH
Install in the reverse order of removal.
2. SUB-SWITCH
Install in the reverse order of removal.GW-00327
GW-00328
GW-00007
GW-00008
Page 338 of 2870
GW-8
GLASS/WINDOW/MIRROR
Power Window Control Switch
C: INSPECTION
1. MAIN SWITCH
Measure the switch resistance.
LHD model
If NG, replace the main switch.
Switch position Terminal No. Standard
Driver’s sideAUTO UP 13 and 2, 1 and 5 Less than 1 Ω
UP 13 and 2, 1 and 5 Less than 1 Ω
OFF1 and 2
1 and 5
2 and 5Less than 1 Ω
DOWN 13 and 1, 2 and 5 Less than 1 Ω
AUTO DOWN 13 and 1, 2 and 5 Less than 1 Ω
Front passenger’s sideUP 13 and 7, 6 and 5 Less than 1 Ω
OFF5 and 6
5 and 7
6 and 7Less than 1 Ω
DOWN 13 and 6, 7 and 5 Less than 1 Ω
Rear LHUP 10 and 13, 11 and 5 Less than 1 Ω
OFF5 and 11
5 and 10
11 and 10Less than 1 Ω
DOWN 13 and 11, 10 and 5 Less than 1 Ω
Rear RHUP 13 and 15, 16 and 5 Less than 1 Ω
OFF5 and 15
5 and 16
15 and 16Less than 1 Ω
DOWN 13 and 16, 15 and 5 Less than 1 Ω
Page 339 of 2870

GW-9
GLASS/WINDOW/MIRROR
Power Window Control Switch
RHD model
If NG, replace the main switch.
2. SUB-SWITCH
Measure the switch resistance.
If NG, replace the sub-switch.
Switch position Terminal No. Standard
Driver’s sideAUTO UP 12 and 7, 6 and 1 Less than 1 Ω
UP 12 and 7, 6 and 1 Less than 1 Ω
OFF1 and 6
1 and 7
6 and 7Less than 1 Ω
DOWN 12 and 6, 7 and 1 Less than 1 Ω
AUTO DOWN 12 and 6, 7 and 1 Less than 1 Ω
Front passenger’s sideUP 12 and 2, 3 and 1 Less than 1 Ω
OFF1 and 2
1 and 3
2 and 3Less than 1 Ω
DOWN 12 and 3, 2 and 1 Less than 1 Ω
Rear LHUP 12 and 10, 9 and 1 Less than 1 Ω
OFF1 and 9
1 and 10
9 and 10Less than 1 Ω
DOWN 12 and 9, 10 and 1 Less than 1 Ω
Rear RHUP 12 and 14, 13 and 1 Less than 1 Ω
OFF1 and 13
1 and 14
13 and 14Less than 1 Ω
DOWN 12 and 13, 14 and 1 Less than 1 Ω
Switch position Terminal No. Standard
Front passenger’s side
and rearUP8 and 5, 6 and 7, 1 and 8, 1 and
5Less than 1 Ω
OFF 4 and 5, 6 and 7 Less than 1 Ω
DOWN8 and 7, 4 and 5, 1 and 8, 1 and
7Less than 1 Ω
Page 340 of 2870
GW-10
GLASS/WINDOW/MIRROR
Remote Control Mirror System
4. Remote Control Mirror System
A: WIRING DIAGRAM
1. REMOTE CONTROL MIRROR
B: INSPECTION
Symptom Repair order
All function does not operate.(1) Fuse (F/B No. 4) (F/B No. 13) (F/B No. 17) (F/B No. 18)
(2) Mirror switch
(3) Wiring harness
One side of the mirror motor does not operate.(1) Mirror switch
(2) Mirror motor
(3) Wiring harness
Heated mirror does not operate.(1) Mirror switch
(2) Heated mirror
(3) Wiring harness
Page 341 of 2870
GW-11
GLASS/WINDOW/MIRROR
Scalp Cap
5. Scalp Cap
A: REPLACEMENT
1) Turn the rearview mirror downward.
2) Insert a thin screw driver, push the clip part of
scalp cap, and remove the scalp cap.
3) Insert the claw at the bottom of scalp cap into
door mirror.
4) Install the scalp cap securely.
GW-00224
GW-00299
Page 342 of 2870
GW-12
GLASS/WINDOW/MIRROR
Outer Mirror Assembly
6. Outer Mirror Assembly
A: REMOVAL
1) Remove the door trim.
AL, Front Door Trim.>
2) Remove the mirror gusset cover.
3) Disconnect the mirror connector.
4) Remove the grommet, and then loosen the
screws to remove mirror assembly.
B: INSTALLATION
Install in the reverse order of removal.
(1) Hook
: (1)
GW-00061
GW-00010
Page 343 of 2870
GW-13
GLASS/WINDOW/MIRROR
Outer Mirror Assembly
C: INSPECTION
Check to ensure that the rearview mirror moves properly when battery voltage is applied to terminals.
Heated mirror not-equipped model:
If NG, replace the mirror.
Heated mirror equipped model:
If NG, replace the mirror.
Switch position Terminal No.
OFF —
UP 1 (+) and 3 (−)
DOWN 3 (+) and 1 (−)
LEFT 2 (+) and 3 (−)
RIGHT 3 (+) and 2 (−)
Switch position Terminal No.
OFF —
UP 2 (+) and 4 (−)
DOWN 4 (+) and 2 (−)
LEFT 3 (+) and 4 (−)
RIGHT 4 (+) and 3 (−)
Page 344 of 2870
GW-14
GLASS/WINDOW/MIRROR
Outer Mirror
7. Outer Mirror
A: REPLACEMENT
1) Remove the door mirror assembly.
12, REMOVAL, Outer Mirror Assembly.>
2) Warm the area around the mirror holder (1) with
a hair drier until the edges of the mirror holder be-
come soft (about 2 or 3 minutes with a 1,000 W dri-
er.)
3) Use a flat tip screwdriver without sharp edges to
lift the mirror out of the mirror holder. (Also discon-
nect the heated mirror connector from the back of
mirror.)
4) When installing the mirror, warm the area around
the mirror holder with a hair drier until the edges of
the mirror holder become soft again (about 2 or 3
minutes with a 1,000 W drier.)
5) Remove the backing of the new double-stick
tape, and push the mirror in to install it.
NOTE:
Unless the mirror holder is warmed sufficiently, the
mirror holder edges may be damaged or the mirror
cracked.
GW-00062
