Page 1433 of 2870

SUBARU FORESTER 2004 Service Repair Manual EC(H4DOTC)-3 EMISSION CONTROL (AUX. EMISSION CONTROL DEVICE) Front Catalytic Converter 2. Front Catalytic Converter A: REMOVAL 1) Remove the center exhaust pipe. <Ref. to EX(H4DOTC)-9, REMOVAL, Cente

Page 1434 of 2870

SUBARU FORESTER 2004 Service Repair Manual EC(H4DOTC)-4 EMISSION CONTROL (AUX. EMISSION CONTROL DEVICE) Rear Catalytic Converter 3. Rear Catalytic Converter A: REMOVAL 1. 2.0 L MODEL 1) Remove the center exhaust pipe. <Ref. to EX(H4DOTC)-9, R

Page 1435 of 2870

SUBARU FORESTER 2004 Service Repair Manual EC(H4DOTC)-5 EMISSION CONTROL (AUX. EMISSION CONTROL DEVICE) Precatalytic Converter 4. Precatalytic Converter A: REMOVAL Precatalytic converter (A) is built in the joint pipe. Refer to the removal of

Page 1436 of 2870

SUBARU FORESTER 2004 Service Repair Manual EC(H4DOTC)-6 EMISSION CONTROL (AUX. EMISSION CONTROL DEVICE) Canister 5. Canister A: REMOVAL 1) Lift-up the vehicle. 2) Loosen the two clamps which hold two canister hoses, and disconnect the three ev

Page 1437 of 2870

SUBARU FORESTER 2004 Service Repair Manual EC(H4DOTC)-7 EMISSION CONTROL (AUX. EMISSION CONTROL DEVICE) Purge Control Solenoid Valve 6. Purge Control Solenoid Valve A: REMOVAL 1) Disconnect the ground cable from battery. 2) Disconnect the conn

Page 1438 of 2870

SUBARU FORESTER 2004 Service Repair Manual EC(H4DOTC)-8 EMISSION CONTROL (AUX. EMISSION CONTROL DEVICE) Two-way Valve 7. Two-way Valve A: REMOVAL 1) Lift-up the vehicle. 2) Remove the canister from body. <Ref. to EC(H4DOTC)-6, REMOVAL, Caniste

Page 1439 of 2870

SUBARU FORESTER 2004 Service Repair Manual FUJI HEAVY INDUSTRIES LTD. G8080GE3 2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX ENGINE SECTION 2 This service manual has been prepared to provide SUBARU service personnel with the necessary inf
