SUBARU FORESTER 2004 Service Repair Manual LU(H4SO)-21
LUBRICATION
Engine Oil Cooler
7. Engine Oil Cooler
A: REMOVAL
NOTE:
Engine oil cooler is equipped with turbo model only.
1) Lift-up the vehicle.
2) Remove the under cover.
3) Drain the eng

Page 1050 of 2870

SUBARU FORESTER 2004 Service Repair Manual LU(H4SO)-22
LUBRICATION
Engine Oil Cooler
B: INSTALLATION
NOTE:
Engine oil cooler is equipped with turbo model only.
1) Install in the reverse order of removal.
2) Contact the knock pin (A) of adapter

Page 1051 of 2870

SUBARU FORESTER 2004 Service Repair Manual LU(H4SO)-23
LUBRICATION
Engine Oil Filter
8. Engine Oil Filter
A: REMOVAL
1) Remove six clips on the under cover.
2) Turn the service hole cover counterclockwise.
3) Remove the oil filter with ST.
ST

Page 1052 of 2870

SUBARU FORESTER 2004 Service Repair Manual LU(H4SO)-24
LUBRICATION
Engine Lubrication System Trouble in General
9. Engine Lubrication System Trouble in General
A: INSPECTION
Before performing diagnostics, make sure that the engine oil level is

Page 1053 of 2870

SUBARU FORESTER 2004 Service Repair Manual FUJI HEAVY INDUSTRIES LTD. G8080GE2
2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX
ENGINE SECTION 1
This service manual has been prepared
to provide SUBARU service personnel
with the necessary inf

Page 1054 of 2870

SUBARU FORESTER 2004 Service Repair Manual SPEED CONTROL SYSTEM
SP(H4SO)
Page
1. General Description ....................................................................................2
2. Accelerator Pedal ...................................

Page 1055 of 2870

SUBARU FORESTER 2004 Service Repair Manual SP(H4SO)-2
SPEED CONTROL SYSTEM
General Description
1. General Description
A: SPECIFICATION
B: COMPONENT
1. LHD MODEL
Accelerator pedalFree play At pedal pad 0 — 4 mm (0 — 0.16 in)
Stroke At pedal

Page 1056 of 2870

SUBARU FORESTER 2004 Service Repair Manual SP(H4SO)-3
SPEED CONTROL SYSTEM
General Description
2. RHD MODEL
C: CAUTION
Wear work clothing, including a cap, protective
goggles, and protective shoes during operation.
Remove contamination, in
