2004 SUBARU FORESTER Service Repair Manual

park assist brake rotor oil viscosity service interval reset remote start tire pressure reset

Load previous 8 pages

Page 889 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-20
MECHANICAL
General Description
499587500 OIL SEAL
INSTALLERUsed for installing camshaft oil seal.
499587700 CAMSHAFT OIL
SEAL INSTALLERUsed for installing cylinder head plug.
499097700 P

Page 890 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-21
MECHANICAL
General Description
499497000 TORX PLUS Used for removing and installing camshaft cap.
499587100 OIL SEAL
INSTALLERUsed for installing oil pump oil seal.
499597000 OIL SEAL GUI

Page 891 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-22
MECHANICAL
General Description
499718000 VALVE SPRING
REMOVERUsed for removing and installing valve spring.
499767200 VALVE GUIDE
REMOVERUsed for removing valve guides.
499767400 VALVE G

Page 892 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-23
MECHANICAL
General Description
2. GENERAL TOOL
499817100 ENGINE STAND Stand used for engine disassembly and
assembly.
Used with ENGINE STAND ADAPTER RH
(498457000) & LH (498457100).

Page 893 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-24
MECHANICAL
General Description
E: PROCEDURE
It is possible to conduct the following service proce-
dures with engine on the vehicle, however, the pro-
cedures described in this section are

Page 894 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-25
MECHANICAL
Compression
2. Compression
A: INSPECTION
CAUTION:
After warming-up, engine becomes very hot. Be
careful not to burn yourself during measure-
ment.
1) After warming-up the engin

Page 895 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-26
MECHANICAL
Idle Speed
3. Idle Speed
A: INSPECTION
1) Before checking idle speed, check the following:
(1) Ensure the air cleaner element is free from
clogging, ignition timing is correct,

ME(H4SO)-26
MECHANICAL
Idle Speed
3. Idle Speed
A: INSPECTION
1) Before checking idle speed, check the following:
(1) Ensure the air cleaner element is free from
clogging, ignition timing is correct, spark plugs
are in good condition, and the hoses are con-
nected properly.
(2) Ensure the malfunction indicator light does
not illuminate.
2) Warm-up the engine.
3) Stop the engine, and then turn the ignition switch
to OFF.
4) When using the Subaru Select Monitor, refer to
the following. TOOL, PREPARATION TOOL, General Descrip-
tion.>
(1) Insert the cartridge to Subaru Select Moni-
tor.
(2) Connect the Subaru Select Monitor to data
link connector.
(3) Turn the ignition switch to ON, and Subaru
Select Monitor switch to ON.
(4) Select the {Each System Check} in Main
Menu.
(5) Select the {Engine Control System} in Se-
lection Menu.
(6) Select the {Current Data Display & Save} in
Engine Control System Diagnosis.
(7) Select the {Data Display} in Data Display
Menu.
(8) Start the engine, and then read the engine
idle speed.
5) When using the tachometer (Secondary pick-up
type).
(1) Attach the pick-up clip to No. 1 cylinder
spark plug cord.(2) Start the engine, and then read the engine
idle speed.
NOTE:
When using the OBD-II general scan tool, care-
fully read its operation manual.
This ignition system provides simultaneous igni-
tion for #1 and #2 plugs. It must be noted that some
tachometers may register twice that of actual en-
gine speed.
6) Check the idle speed when unloaded. (With
headlights, heater fan, rear defroster, radiator fan,
air conditioning, etc. OFF)
Idle speed [No load and gears in “N” or “P”
range]:
650
±100 rpm
7) Check the idle speed when loaded. (Turn the air
conditioning switch to “ON” and operate the com-
pressor for at least 1 minute before measurement.)
Idle speed [A/C “ON”, no load and gears in “N”
or “P” range]:
850
±100 rpm
NOTE:
Idle speed can not be adjusted manually, because
the idle speed is automatically adjusted.
If the specified idle speed can not be maintained,
refer to General On-board Diagnosis Table under
“Engine Control System”. Basic Diagnostics Procedure.>
ME-00325
ME-00193

Page 896 of 2870

SUBARU FORESTER 2004 Service Repair Manual ME(H4SO)-27
MECHANICAL
Ignition Timing
4. Ignition Timing
A: INSPECTION
CAUTION:
After warming-up, engine becomes very hot. Be
careful not to burn yourself during measure-
ment.
1) Warm-up the engine

Load next 8 pages
