SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-51
FUEL INJECTION (FUEL SYSTEM)
Fuel Filler Pipe
21.Fuel Filler Pipe
A: REMOVAL
WARNING:
Place “NO FIRE” signs near the working area.
Be careful not to spill fuel.
1) Set the vehicle

Page 834 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-52
FUEL INJECTION (FUEL SYSTEM)
Fuel Filler Pipe
13) Disconnect the air vent hose from fuel filler
pipe.
14) Remove the bolts which hold fuel filler pipe
bracket on body.
15) Loosen the clamp

Page 835 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-53
FUEL INJECTION (FUEL SYSTEM)
Fuel Filler Pipe
6) Insert the fuel filler hose (A) approx. 35 to 40 mm
(1.38 to 1.57 in) over the lower end of fuel filler pipe
and tighten the clamp.
CAUTION

Page 836 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-54
FUEL INJECTION (FUEL SYSTEM)
Fuel Filler Pipe
15) Connect the battery ground cable to battery.
FU-00009

Page 837 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-55
FUEL INJECTION (FUEL SYSTEM)
Fuel Pump
22.Fuel Pump
A: REMOVAL
WARNING:
Place “NO FIRE” signs near the working area.
Be careful not to spill fuel.
NOTE:
Fuel pump assembly consist

Page 838 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-56
FUEL INJECTION (FUEL SYSTEM)
Fuel Pump
11) Move the clips, and then disconnect the fuel re-
turn hose (A) and jet pump hose (B).
12) Remove the nuts which install fuel pump as-
sembly onto

Page 839 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-57
FUEL INJECTION (FUEL SYSTEM)
Fuel Level Sensor
23.Fuel Level Sensor
A: REMOVAL
WARNING:
Place “NO FIRE” signs near the working area.
Be careful not to spill fuel.
NOTE:
Fuel level

Page 840 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-58
FUEL INJECTION (FUEL SYSTEM)
Fuel Sub Level Sensor
24.Fuel Sub Level Sensor
A: REMOVAL
WARNING:
Place “NO FIRE” signs near the working area.
Be careful not to spill fuel.
1) Discon
