Page 1617 of 2870

SUBARU FORESTER 2004 Service Repair Manual IGNITION IG(H4DOTC) Page 1. General Description ....................................................................................2 2. Spark Plug.....................................................

Page 1618 of 2870

SUBARU FORESTER 2004 Service Repair Manual IG(H4DOTC)-2 IGNITION General Description 1. General Description A: SPECIFICATION Item Designation Ignition coil and ignitor ASSYModel FK0186 Ignition type Direct ignition Manufacturer DIAMOND Spark

Page 1619 of 2870

SUBARU FORESTER 2004 Service Repair Manual IG(H4DOTC)-3 IGNITION General Description B: COMPONENT (1) Spark plug (2) Ignition coil & ignitor ASSYTightening torque: N⋅m (kgf-m, ft-lb) T1: 21 (2.1, 15.2) T2: 16 (1.6, 11.7) IG-00001 (1)T1 T2 T1

Page 1620 of 2870

SUBARU FORESTER 2004 Service Repair Manual IG(H4DOTC)-4 IGNITION General Description C: CAUTION  Wear working clothing, including a cap, protec- tive goggles, and protective shoes during opera- tion.  Remove contamination including dirt and

Page 1621 of 2870

SUBARU FORESTER 2004 Service Repair Manual IG(H4DOTC)-5 IGNITION Spark Plug 2. Spark Plug A: REMOVAL CAUTION: All spark plugs installed on an engine, must be of the same heat range. <Ref. to IG(H4DOTC)-2, General Description.> 1. RH SIDE 1)

Page 1622 of 2870

SUBARU FORESTER 2004 Service Repair Manual IG(H4DOTC)-6 IGNITION Spark Plug 5) Disconnect the connector from ignition coil. 6) Remove the ignition coil. 7) Remove the spark plugs with the spark plug sockets. B: INSTALLATION 1. RH SIDE Install

Page 1623 of 2870

SUBARU FORESTER 2004 Service Repair Manual IG(H4DOTC)-7 IGNITION Spark Plug 2) Carbon fouled: Dry fluffy carbon deposits on insulator and elec- trode are mostly caused by slow speed driving in city, weak ignition, too rich fuel mixture, dirty

Page 1624 of 2870

SUBARU FORESTER 2004 Service Repair Manual IG(H4DOTC)-8 IGNITION Ignition Coil & Ignitor ASSY 3. Ignition Coil & Ignitor ASSY A: REMOVAL Direct ignition type has been adopted. Refer to the “SparkPlug Removal” for removal procedure. <Ref. t
