Page 793 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-11 FUEL INJECTION (FUEL SYSTEM) General Description 6. FUEL FILLER PIPE (1) Fuel filler pipe ASSY (6) Air vent pipe (11) Fuel filler cap tether (2) Evaporation hose holder (7) Air vent pipe h

Page 794 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-12 FUEL INJECTION (FUEL SYSTEM) General Description C: CAUTION  Wear working clothing, including a cap, protec- tive goggles, and protective shoes during opera- tion.  Remove contamination

Page 795 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-13 FUEL INJECTION (FUEL SYSTEM) Throttle Body 2. Throttle Body A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the air cleaner case. <Ref. to IN(H4SO)-6, REMOVAL, Air Cleane

Page 796 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-14 FUEL INJECTION (FUEL SYSTEM) Intake Manifold 3. Intake Manifold A: REMOVAL 1) Release the fuel pressure. <Ref. to FU(H4SO)- 47, RELEASING OF FUEL PRESSURE, OPERA- TION, Fuel.> 2) Open the

Page 797 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-15 FUEL INJECTION (FUEL SYSTEM) Intake Manifold (7) Place the power steering pump on the right side wheel apron. 8) Disconnect the spark plug cords from the spark plugs. 9) Disconnect the PCV

Page 798 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-16 FUEL INJECTION (FUEL SYSTEM) Intake Manifold 16) Disconnect the connector from the oil pressure switch. 17) Disconnect the connector from the camshaft position sensor. 18) Remove the EGR p

Page 799 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-17 FUEL INJECTION (FUEL SYSTEM) Intake Manifold 2) Connect the fuel hoses. 3) Connect the EGR pipe to intake manifold. Tightening torque: 34 N ⋅m (3.4 kgf-m, 24.6 ft-lb) 4) Connect the conn

Page 800 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4SO)-18 FUEL INJECTION (FUEL SYSTEM) Intake Manifold 10) Connect the brake booster hose. 11) Connect the engine coolant hose (A) to the throttle body. 12) Connect the PCV hose to the intake manifo
