Page 2849 of 2870
CL-23
CLUTCH SYSTEM
Release Bearing and Lever
2. RELEASE LEVER
Check the lever pivot portion and the point of con-
tact with release bearing case for wear.
(A) Clutch release lever
(B) Pivot
(C) Clutch release bearing
CL-00034
(A)
(B)
(C)
Page 2850 of 2870
CL-24
CLUTCH SYSTEM
Operating Cylinder
5. Operating Cylinder
A: REMOVAL
1) Remove the air cleaner case and air intake duct
(Non-turbo model).
AL, Air Cleaner Case.>
MOVAL, Air Intake Duct.>
2) Remove the intercooler (Turbo model).
IN(H4DOTC)-10, REMOVAL, Intercooler.>
3) Remove the clutch hose from operating cylinder.
NOTE:
Cover the hose joint to prevent clutch fluid from
flowing out.
NON-TURBO model
TURBO model4) Remove the operating cylinder from transmis-
sion.
NON-TURBO model
TURBO model
(A) Clutch hose
(B) Operating cylinder
(A) Clutch hose
(B) Operating cylinder
CL-00035
(A)
(B)
CL -00036
(B)
(A)
(A) Operating cylinder
CL-00037
CL-00038
(A)
Page 2851 of 2870

CL-25
CLUTCH SYSTEM
Operating Cylinder
B: INSTALLATION
1) Apply grease (SUNLIGHT 2: Part No.
003602010) to the contact point of the release lever
and operating cylinder.
2) Install in the reverse order of removal.
Before installing the operating cylinder, apply
grease (SUNLIGHT 2: Part No. 003602010) to con-
tact point of the release lever and operating cylin-
der.
Tightening torque:
T1: 18 N
⋅m (1.8 kgf-m, 13.0 ft-lb)
T2: 37 N
⋅m (3.8 kgf-m, 27.5 ft-lb)
NON-TURBO model
TURBO modelNOTE:
Be sure to install the clutch hose with the mark
side facing upward.
Be careful not to twist the clutch hose during in-
stallation.
3) After bleeding air from the operating cylinder,
ensure that clutch operates properly.
C: INSPECTION
1) Check the operating cylinder for damage. If op-
erating cylinder is damaged, replace it.
2) Check the operating cylinder for fluid leakage or
damage on boot. If any leakage or damage is
found, replace the operating cylinder.
T2
CL-00039T2
T1
CL-00040
T2
T1
(A) Marking
(B) Clutch hose
(C) Operating cylinder
CL-00041
(A)
(B) (C)
Page 2852 of 2870

CL-26
CLUTCH SYSTEM
Master Cylinder
6. Master Cylinder
A: REMOVAL
1) Thoroughly drain the brake fluid from reservoir
tank.
2) Remove the snap pin, clevis pin and separate
the push rod of master cylinder from clutch pedal.
3) Remove the air cleaner case and air intake duct
(Non-turbo model).
AL, Air Cleaner Case.>
MOVAL, Air Intake Duct.>
4) Remove the intercooler (Turbo model).
IN(H4DOTC)-10, REMOVAL, Intercooler.>
5) Remove the clutch pipe from master cylinder.
6) Remove the master cylinder with reservoir tank.
CAUTION:
Be extremely careful not to spill brake fluid.
Brake fluid spilt on the vehicle body will harm
the paint surface; wipe it off quickly if spilt.
B: INSTALLATION
1) Install the master cylinder to body, and install the
clutch pipe to master cylinder.
NOTE:
Check that the pipe is routed properly.
Tightening torque:
T1: 15 N
⋅m (1.5 kgf-m, 10.8 ft-lb)
T2: 18 N
⋅m (1.8 kgf-m, 13.0 ft-lb)
2) Apply a coat of grease to the clevis pin.
3) Connect the push rod of master cylinder to
clutch pedal, and install the new clevis pin and
snap pin.
4) After bleeding air from the system, ensure that
clutch operates properly.
5) Install the air cleaner case and air intake duct
(Non-turbo model).
LATION, Air Cleaner Case.>
INSTALLATION, Air Intake Duct.>
6) Install the intercooler (Turbo model).
IN(H4DOTC)-11, INSTALLATION, Intercooler.>
(A) Clevis pin
(B) Snap pin
(C) Push rod
(D) Push rod lock nut
CL-00042
(A)
(B)
(C)(D)
CL-00137
(A) Clevis pin
(B) Snap pin
(C) Push rod
CL-00163
T2T1
CL-00045
(A)
(B)
(C)
Page 2853 of 2870
CL-27
CLUTCH SYSTEM
Master Cylinder
C: DISASSEMBLY
1. EXCEPT RHD TURBO MODEL
1) Remove the straight pin and reservoir tank.
2) Remove the oil seal.
3) Move the cylinder boot backward.
4) Remove the stop ring.
CAUTION:
Be careful when removing the stop ring to pre-
vent the rod, washer, piston and return spring
from flying out.
2. RHD TURBO MODEL
1) Remove the hose.
2) Remove the reservoir tank and bracket.
3) Remove the straight pin and adapter.
4) Remove the oil seal.
(A) Reservoir tank
(B) Straight pin
(A) Oil seal
(B) Master cylinder
(A) Cylinder boot
(B) Master cylinder
CL-00046
(A)
(B)
CL-00047
(A)
(B)
CL-00048
(A)
(B)
(A) Reservoir tank
(B) Bracket
(A) Straight pin
(B) Adapter
CL-00049
CL-00050
(A)(B)
CL-00051 (A)(B)
CL-00052
Page 2854 of 2870

CL-28
CLUTCH SYSTEM
Master Cylinder
5) Move the cylinder boot backward.
6) Remove the stop ring.
CAUTION:
Be careful when removing the stop ring to pre-
vent the rod, washer, piston and return spring
from flying out.
7) Remove the air bleeder.
D: ASSEMBLY
1. EXCEPT RHD TURBO MODEL
1) Apply a coat of grease to the contacting surfaces
of the push rod and piston before installation.
Grease:
SILICONE GREASE G40M (Part No.
004404003)
2) To assemble the master cylinder, reverse the
sequence of disassembly procedure.
Tightening torque:
10 N
⋅m (1.0 kgf-m, 7 ft-lb)
2. RHD TURBO MODEL
1) Apply a coat of grease to the contacting surfaces
of the push rod and piston before installation.
Grease:
SILICONE GREASE G40M (Part No.
004404003)
2) Assemble in the reverse order of disassemble.
E: INSPECTION
If any damage, deformation, wear, swelling, rust or
other faults are found on the cylinder, piston, push
rod, fluid reservoir, return spring, gasket, cylinder
boot and hose replace the faulty part.
(A) Cylinder boot
(B) Master cylinder
CL-00048
(A)
(B)
CL-00054
(A) Master cylinder body
(B) Return spring
(C) Piston
(D) Stop ring
(E) Rod ASSY
(F) Clutch damper
(G) Cylinder boot
CL-00055
CL-00056
(B)
(C)
(D)
(E) (A)
(F)
(G)
Page 2855 of 2870
CL-29
CLUTCH SYSTEM
Clutch Pipe and Hose
7. Clutch Pipe and Hose
A: REMOVAL
1. EXCEPT RHD TURBO MODEL
1) Remove the air cleaner case and air intake
chamber.
2) Drain the clutch fluid.
id.>
3) Remove the clutch pipe from the clutch hose and
master cylinder.
4) Pull out the clamp, then remove the clutch hose
from bracket.
5) Remove the hose from operating cylinder.
6) Remove the bracket.
2. RHD TURBO MODEL
1) Remove the intercooler.
10, REMOVAL, Intercooler.>
2) Drain the clutch fluid.
id.>
3) Remove the clutch pipe from the master cylin-
der, connector and clutch hose.
4) Pull out the clamp, then remove the clutch hose
from bracket.
5) Remove the hose from operating cylinder.
6) Remove the bracket.
(A) Clamp
(B) Clutch hose
CL-00057
(A)
(B)
(A) Clutch pipe
(B) Clip
(C) Connector
(D) Clutch hose
(A) Clamp
(B) Clutch hose
CL-00053
(A)
(B)(B) (B)
(A)
(D)
(A)
(C )
CL-00057
(A)
(B)
Page 2856 of 2870
CL-30
CLUTCH SYSTEM
Clutch Pipe and Hose
B: INSTALLATION
1. EXCEPT RHD TURBO MODEL
Install in the reverse order of removal.
Tightening torque:
T1: 15 N
⋅m (1.5 kgf-m, 10.8 ft-lb)
T2: 18 N
⋅m (1.8 kgf-m, 13.0 ft-lb)
T3: 25 N
⋅m (2.5 kgf-m, 18.1 ft-lb)
2. RHD TURBO MODEL
Install in the reverse order of removal.
Tightening torque:
T1: 7.5 N
⋅m (0.76 kgf-m, 5.53 ft-lb)
T2: 8 N
⋅m (0.8 kgf-m, 5.8 ft-lb)
T3: 15 N
⋅m (1.5 kgf-m, 10.8 ft-lb)
T4: 18 N
⋅m (1.8 kgf-m, 13.0 ft-lb)
T5: 25 N
⋅m (2.5 kgf-m, 18.1 ft-lb)
C: INSPECTION
Check the pipes and hoses for cracks, breakage, or
damage. Check the joints for fluid leakage. If any
cracks, breakage, damage, or leakage is found, re-
pair or replace the applicable pipe or hose.
(A) Clutch pipe (LHD model)
(B) Clip
(C) Clutch hose
(D) Clutch pipe (RHD model)
(D)
(B) (C)(A)
T1
T1
T2
T1
T3
CL-00125
(A) Clutch pipe
(B) Connector
(C) Clutch hose
(A)
(A) (A)
T3
T3T3
T3
T1
T3
T5
T5
(C)
T2
T4
(B)
CL-00061
