Page 49 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-47 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) Heater Duct 22.Heater Duct A: REMOVAL 1) Remove the front seat. <Ref. to SE-6, REMOV- AL, Front Seat.> 2) Remove the front side sill cover. 3) Pull off t

Page 50 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-48 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) Heater Vent Duct 23.Heater Vent Duct A: REMOVAL 1) Remove the instrument panel. <Ref. to EI-40, REMOVAL, Instrument Panel Assembly.> 2) Remove the screw

Page 51 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-49 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) Heater Cock Solenoid Valve 24.Heater Cock Solenoid Valve A: REMOVAL 1) Drain the engine coolant. <Ref. to CO(H4SO)-19, DRAINING OF ENGINE COOLANT, REPLAC

Page 52 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-50 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) General Diagnostics 25.General Diagnostics A: INSPECTION Symptom Repair order Blower motorDoes not run.Fuse Blower motor relay Wiring harness Blower moto

Page 53 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-51 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) General Diagnostics Temperature of air from vents does not change.Wiring harness Air mix actuator (Auto A/C), Temperature control cable (Manual A/C) Tem

Page 54 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-52 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) General Diagnostics

Page 55 of 2870

SUBARU FORESTER 2004 Service Repair Manual FUJI HEAVY INDUSTRIES LTD. G8080GE7 2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX BODY SECTION This service manual has been prepared to provide SUBARU service personnel with the necessary informa

Page 56 of 2870

SUBARU FORESTER 2004 Service Repair Manual 2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX BODY SECTION G8080GE7 CRUISE CONTROL SYSTEM CC CRUISE CONTROL SYSTEM (DIAGNOSTIC)CC(H4SO) CRUISE CONTROL SYSTEM (DIAGNOSTIC)CC(H4DOTC) CRUISE CONTROL
