SUBARU FORESTER 2004 Service Repair Manual IG(H4SO)-9 IGNITION Spark Plug Cord 4. Spark Plug Cord A: INSPECTION Check for: 1) Damage to cords, deformation, burning or rust formation of terminals 2) Resistance values of cords Resistance value:

Page 1074 of 2870

SUBARU FORESTER 2004 Service Repair Manual IG(H4SO)-10 IGNITION Spark Plug Cord

Page 1075 of 2870

SUBARU FORESTER 2004 Service Repair Manual FUJI HEAVY INDUSTRIES LTD. G8080GE2 2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX ENGINE SECTION 1 This service manual has been prepared to provide SUBARU service personnel with the necessary inf

Page 1076 of 2870

SUBARU FORESTER 2004 Service Repair Manual STARTING/CHARGING SYSTEM SC(H4SO) Page 1. General Description ....................................................................................2 2. Starter .........................................

Page 1077 of 2870

SUBARU FORESTER 2004 Service Repair Manual SC(H4SO)-2 STARTING/CHARGING SYSTEM General Description 1. General Description A: SPECIFICATION Item Designation StarterType Reduction type Vehicle type MT model AT model Model M000T30471 M000T20171 M

Page 1078 of 2870

SUBARU FORESTER 2004 Service Repair Manual SC(H4SO)-3 STARTING/CHARGING SYSTEM General Description B: COMPONENT 1. STARTER (1) Front bracket (7) Internal gear ASSY (13) Brush holder ASSY (2) Sleeve bearing (8) Shaft ASSY (14) Sleeve bearing (3

Page 1079 of 2870

SUBARU FORESTER 2004 Service Repair Manual SC(H4SO)-4 STARTING/CHARGING SYSTEM General Description 2. GENERATOR (1) Pulley (5) Rotor (9) Brush (2) Front cover (6) Bearing (10) Rectifier (3) Ball bearing (7) Stator coil (11) Rear cover (4) Bear

Page 1080 of 2870

SUBARU FORESTER 2004 Service Repair Manual SC(H4SO)-5 STARTING/CHARGING SYSTEM General Description C: CAUTION  Wear working clothing, including a cap, protec- tive goggles, and protective shoes during opera- tion.  Remove contamination inclu
