Remote Control Mirror System
4. Remote Control Mirror System
A: WIRING DIAGRAM
1. REMOTE CONTROL MIRROR

B: INSPECTION
Symptom Repair order
All function does not operate.(1) Fuse (F/B No. 4) (F/B No. 13) (F/B No. 17) (F/B No. 18)
(2) Mirror switch
(3) Wiring harness
One side of the mirror motor does not operate.(1) Mirror switch
(2) Mirror motor
(3) Wiring harness
Heated mirror does not operate.(1) Mirror switch
(2) Heated mirror
(3) Wiring harness

GW-15
GLASS/WINDOW/MIRROR
Remote Control Mirror Switch
8. Remote Control Mirror
Switch
A: REMOVAL
Refer to Power Window Control Switch, because the
remote control mirror switch is integrated with power
window control switch. Power Window Control Switch.>
B: INSTALLATION
Refer to Power Window Control Switch, because the
remote control mirror switch is integrated with power
window control switch. TION, Power Window Control Switch.>

GW-16
GLASS/WINDOW/MIRROR
Remote Control Mirror Switch
C: INSPECTION
Move the rearview mirror switch to each position
and check continuity between terminals.
Change over switch right position:
Change over switch left position:
If NG, replace the switch.
GW-00012
1 2
3 4 5 6
7 8 910
Switch position Terminal No. Standard
OFF — More than 1MΩ
UP 8 and 3, 6 and 7 Less than 1Ω
DOWN 8 and 6, 3 and 7 Less than 1Ω
LEFT 8 and 2, 6 and 7 Less than 1Ω
RIGHT 8 and 6, 2 and 7 Less than 1Ω
Switch position Terminal No. Standard
OFF — More than 1MΩ
UP 8 and 4, 6 and 7 Less than 1Ω
DOWN 8 and 6, 4 and 7 Less than 1Ω
LEFT 8 and 5, 6 and 7 Less than 1Ω
RIGHT 8 and 6, 5 and 7 Less than 1Ω

SECURITY AND LOCK
SL
Page
1. General Description ....................................................................................2
2. Door Lock Control System ..........................................................................9
3. Keyless Entry System ...............................................................................14
4. Front Inner Remote ...................................................................................22
5. Front Outer Handle ...................................................................................23
6. Front Door Latch Assembly.......................................................................24
7. Front Door Lock Actuator ..........................................................................25
8. Rear Inner Remote....................................................................................26
9. Rear Outer Handle ....................................................................................27
10. Rear Door Latch Assembly .......................................................................28
11. Rear Door Lock Actuator...........................................................................29
12. Rear Gate Outer Handle ...........................................................................30
13. Rear Gate Latch Assembly .......................................................................31
14. Rear Gate Latch Lock Actuator .................................................................32
15. Front Hood Lock Assembly .......................................................................33
16. Remote Openers .......................................................................................34
17. Ignition Key Lock .......................................................................................35
18. Key Lock Cylinder .....................................................................................36
19. Immobilizer Control Module ......................................................................37
20. Immobilizer Antenna .................................................................................38
21. Keyless Entry Control Module ...................................................................39
22. Double Lock Module .................................................................................40
23. Keyless Transmitter ..................................................................................41

EI-35
EXTERIOR/INTERIOR TRIM
Front Door Trim
11.Front Door Trim
A: REMOVAL
CAUTION:
Do not apply excessive force to the clip. Other-
wise the clip may be broken.
1) Disconnect the ground cable from battery.
2) Remove the gusset cover.
3) Pull up the inner remote cover toward you to re-
move upper hook. Pull down it to remove the lower
hook. Remove the inner remote cover.
4) Remove the power window control switch. to GW-7, REMOVAL, Power Window Control
Switch.>
5) Remove the clips of trim panel using clip remov-
er to remove trim panel.
B: INSTALLATION
Install in the reverse order of removal.
EI-00054
EI-00055

EI-36
EXTERIOR/INTERIOR TRIM
Rear Door Trim
12.Rear Door Trim
A: REMOVAL
